HCD-IS10
SECTION 2
GENERAL
This section is extracted from
instruction manual.
Front panel
A Soft-touch buttons (
N
/
x
/FUNCTION/VOLUME –/+)
B Remote sensor
C Front panel display
D [/1 (on/standby)
E Disc slot
F
Z
(eject)
FUNCTION VOLUME
Rear panel
A AM terminals
B TV (AUDIO IN) jacks
C HDMI OUT jack
D ECM-AC2 jack
E TV (DIGITAL IN OPTICAL) jack
F SAT/CABLE (DIGITAL IN COAXIAL) jack
G VIDEO OUT (VIDEO) jack
H VIDEO OUT (COMPONENT) jacks
I Ventilation slots
J DMPORT jack (Except E32, AR)
K FM 75Ω COAXIAL jack
DMPORT
Front Panel Display
About the indications in the front panel display
A Lights up when the sleep timer is set.
B Lights up when the night mode is on.
C Lights up when a station is received.
(Radio only)
D Lights up when the time information
of a title or chapter appears in the
front panel display. (DVD only)
E Stereo/Monaural effect (Radio only)
F Lights up when the movie or music
mode is selected.
G Current surround format (Except for
JPEG)
H Lights up when an NTSC disc is
loaded. (Except US and Canadian
models)
I Lights up when the HDMI OUT jack is
correctly connected to HDCP (high-
bandwidth digital content protection)
compliant device with HDMI or DVI
(digital visual interface) input.
J Current repeat mode
K Lights up when the system outputs
progressive signals (DVD function
only).
L Lights up when a disc is loaded
(DVD function only).
M Displays system’s status such as
chapter, title, or track number, time
information, radio frequency, playing
status, sound field, etc.
N Playing status (DVD function only)
O Current surround format (Except for
JPEG)
P Lights up when a CD or a DATA CD
is loaded.
SLEEP NIGHT TUNED TITLE CHAP STEREO MONO MOVIE MUSIC NTSC
REPEAT 1
PROGRESSIVE
DIGITAL
CD
