58
HCD-IS10
Pin No.
Pin Name I/O Description
243
LPFOP O Data PLL loop filter output terminal
244
ADCVDD3 - Power supply terminal (+3.3V)
245
ADCVSS - Ground terminal
246
RFVDD3 - Power supply terminal (+3.3V)
247
RFRPDC O RF ripple detect output terminal
248
RFRPAC I RF ripple detect input terminal
249
HRFZC I High frequency RF ripple zero crossing terminal
250
CRTPLP O Defect level filter capacitor connecting terminal
251
RFGND - Ground terminal
252
OSP O RF offset cancellation capacitor connecting terminal
253
OSN O RF offset cancellation capacitor connecting terminal
254
RFGC O RF AGC loop capacitor connecting for DVD-ROM
255
IREF I Reference current input terminal
256
AVDD3 - Power supply terminal (+3.3V)
