Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
73
HCD-IS10
< DIODE >
D3700 8-719-060-48 DIODE RB751V-40TE-17
< FERRITE BEAD >
FB106 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB107 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB108 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB111 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB112 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB115 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB123 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB601 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB602 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB603 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB604 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB605 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB606 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1101 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1103 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1120 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1121 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1122 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1123 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1124 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1125 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB3851 1-469-324-21 FERRITE, EMI (SMD) (2012) (EXCEPT E32, AR)
FB3852 1-469-324-21 FERRITE, EMI (SMD) (2012) (EXCEPT E32, AR)
< FILTER >
FL110 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL601 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL602 1-233-893-21 FILTER, CHIP EMI
FL603 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL701 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL703 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL704 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL3851 1-234-494-21 FILTER, EMI REMOVAL (SMD)
(EXCEPT E32, AR)
< IC >
IC101 6-710-093-01 IC CXD9889R
IC102 6-807-254-01 IC S29AL032D70TF-SHE2-0701UC
(US, CND, E32, AR)
IC102 6-807-255-01 IC S29AL032D70TF-SHE2-0701CE
(AEP, RU, UK, EA, AUS)
IC102 6-807-256-01 IC S29AL032D70TF-SHE2-0701GA
(SP, TW, CH)
IC103 (Not supplied) IC BR24L64F-WE2
IC104 6-709-370-01 IC A2V64S40CTP-G75
IC105 6-702-302-01 IC TK11133CSCL-G
IC107 6-702-302-01 IC TK11133CSCL-G
IC110 6-707-739-01 IC MM1661JTRE
IC111 6-704-100-01 IC TC7PAU04FU (TE85R)
IC201 6-704-524-01 IC FAN8036L
IC701 6-708-682-01 IC CXD9873Q
IC702 6-702-300-01 IC TK11118CSCL-G
IC703 6-702-302-01 IC TK11133CSCL-G
IC705 8-759-592-47 IC TC7SZ08FU (TE85R)
IC707 6-705-337-01 IC TK11150CSCL-G
IC3801 8-759-357-68 IC NJM2115M-TE2 (EXCEPT E32, AR)
< COIL >
L3802 1-469-525-91 INDUCTOR 10uH (EXCEPT E32, AR)
* LF701 1-813-308-11 COMMON MODE CHOKE
* LF702 1-813-308-11 COMMON MODE CHOKE
* LF703 1-813-308-11 COMMON MODE CHOKE
* LF704 1-813-308-11 COMMON MODE CHOKE
< TRANSISTOR >
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q701 6-550-008-01 TRANSISTOR UM6K1N-TN
Q2001 8-729-025-28 FET 2SK1828
Q3700 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q3701 8-729-905-35 TRANSISTOR 2SC4081-R
Q3702 8-729-905-35 TRANSISTOR 2SC4081-R
Q3703 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-295-91 SHORT CHIP 0
R103 1-216-864-11 SHORT CHIP 0
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
R121 1-216-801-11 METAL CHIP 22 5% 1/10W
R123 1-216-864-11 SHORT CHIP 0
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R126 1-216-833-11 METAL CHIP 10K 5% 1/10W
R132 1-216-845-11 METAL CHIP 100K 5% 1/10W
R133 1-216-864-11 SHORT CHIP 0
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-835-11 METAL CHIP 15K 5% 1/10W
R138 1-216-809-11 METAL CHIP 100 5% 1/10W
R139 1-216-864-11 SHORT CHIP 0
R140 1-216-833-11 METAL CHIP 10K 5% 1/10W
R141 1-216-855-11 METAL CHIP 680K 5% 1/10W
R142 1-216-845-11 METAL CHIP 100K 5% 1/10W
R143 1-216-805-11 METAL CHIP 47 5% 1/10W
R145 1-216-864-11 SHORT CHIP 0
R147 1-216-864-11 SHORT CHIP 0
R148 1-216-864-11 SHORT CHIP 0
DMB-IVHD
Note: EEPROM (IC103) cannot exchange with single.
When EEPROM (IC103) is damaged, exchange
the entire mounted board.
