Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
75
HCD-IS10
R1140 1-216-864-11 SHORT CHIP 0
R1141 1-216-864-11 SHORT CHIP 0
R1142 1-216-864-11 SHORT CHIP 0
R1143 1-216-864-11 SHORT CHIP 0
R1146 1-216-864-11 SHORT CHIP 0
R1150 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1151 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1152 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1161 1-216-809-11 METAL CHIP 100 5% 1/10W
R1167 1-216-864-11 SHORT CHIP 0
R1168 1-216-813-11 METAL CHIP 220 5% 1/10W
R1169 1-216-805-11 METAL CHIP 47 5% 1/10W
R1174 1-216-864-11 SHORT CHIP 0
R1176 1-216-864-11 SHORT CHIP 0
R1177 1-216-809-11 METAL CHIP 100 5% 1/10W
R1178 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1179 1-216-809-11 METAL CHIP 100 5% 1/10W
R1180 1-216-864-11 SHORT CHIP 0
R1183 1-216-813-11 METAL CHIP 220 5% 1/10W
R1184 1-216-809-11 METAL CHIP 100 5% 1/10W
R1185 1-216-809-11 METAL CHIP 100 5% 1/10W
R1186 1-216-864-11 SHORT CHIP 0
R1187 1-216-805-11 METAL CHIP 47 5% 1/10W
R1191 1-216-864-11 SHORT CHIP 0
R1505 1-216-864-11 SHORT CHIP 0
R1705 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1706 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1751 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2501 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2502 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3700 1-216-864-11 SHORT CHIP 0
R3701 1-216-813-11 METAL CHIP 220 5% 1/10W
R3702 1-216-838-11 METAL CHIP 27K 5% 1/10W
R3704 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3705 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3706 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3707 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3708 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3709 1-216-864-11 SHORT CHIP 0
R3710 1-216-864-11 SHORT CHIP 0
R3712 1-216-864-11 SHORT CHIP 0
R3801 1-216-864-11 SHORT CHIP 0 (EXCEPT E32, AR)
R3803 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
(EXCEPT E32, AR)
R3804 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
(EXCEPT E32, AR)
R3805 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
(EXCEPT E32, AR)
R3806 1-218-285-11 METAL CHIP 75 5% 1/10W
(EXCEPT E32, AR)
R3807 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
(EXCEPT E32, AR)
R3808 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EXCEPT E32, AR)
R3810 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
(EXCEPT E32, AR)
R3811 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EXCEPT E32, AR)
R3813 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
(EXCEPT E32, AR)
R3814 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
(EXCEPT E32, AR)
R3815 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
(EXCEPT E32, AR)
R3816 1-216-809-11 METAL CHIP 100 5% 1/10W
(EXCEPT E32, AR)
R3817 1-216-809-11 METAL CHIP 100 5% 1/10W
(EXCEPT E32, AR)
R4321 1-216-864-11 SHORT CHIP 0
R4701 1-216-864-11 SHORT CHIP 0
R4702 1-216-864-11 SHORT CHIP 0
R4703 1-216-864-11 SHORT CHIP 0
R4704 1-216-864-11 SHORT CHIP 0
R4705 1-216-864-11 SHORT CHIP 0
R4706 1-216-864-11 SHORT CHIP 0
R5001 1-216-864-11 SHORT CHIP 0 (US, CND, E32, AR)
R5002 1-216-864-11 SHORT CHIP 0 (AEP, RU, UK, EA, AUS)
R5003 1-216-864-11 SHORT CHIP 0 (SP, TW, TH, CH)
< COMPOSITION CIRCUIT BLOCK >
RB103 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB104 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB105 1-234-371-21 RES, NETWORK 47 (1005X4)
RB106 1-234-371-21 RES, NETWORK 47 (1005X4)
RB107 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB108 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB109 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB110 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB111 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB112 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB113 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB114 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB115 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB116 1-234-371-21 RES, NETWORK 47 (1005X4)
RB117 1-234-371-21 RES, NETWORK 47 (1005X4)
RB701 1-234-378-21 RES, NETWORK 10K (1005X4)
RB702 1-234-378-21 RES, NETWORK 10K (1005X4)
< VIBRATOR >
X101 1-795-630-11 VIBRATOR, CRYSTAL (27MHz)
************************************************************
A-1249-889-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C802 1-117-681-11 ELECT CHIP 100uF 20% 16V
C805 1-117-681-11 ELECT CHIP 100uF 20% 16V
C808 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C821 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C822 1-128-405-11 ELECT CHIP 22uF 20% 50V
C823 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C824 1-128-405-11 ELECT CHIP 22uF 20% 50V
C825 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C826 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C827 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
FLDMB-IVHD
Ver. 1.1
