Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
79
HCD-IS10
R305 1-216-864-11 SHORT CHIP 0
R306 1-216-864-11 SHORT CHIP 0
R307 1-216-864-11 SHORT CHIP 0
R315 1-216-864-11 SHORT CHIP 0
R316 1-216-864-11 SHORT CHIP 0
R317 1-216-864-11 SHORT CHIP 0
R318 1-216-864-11 SHORT CHIP 0
R319 1-216-864-11 SHORT CHIP 0
R320 1-216-864-11 SHORT CHIP 0
R321 1-216-864-11 SHORT CHIP 0
R322 1-216-864-11 SHORT CHIP 0
R323 1-216-864-11 SHORT CHIP 0
R324 1-216-864-11 SHORT CHIP 0
R325 1-216-864-11 SHORT CHIP 0
R326 1-216-864-11 SHORT CHIP 0
R327 1-216-864-11 SHORT CHIP 0
R328 1-216-864-11 SHORT CHIP 0
R392 1-216-864-11 SHORT CHIP 0
(US, CND, EA, SP, TW, TH, AUS)
R393 1-216-864-11 SHORT CHIP 0 (AEP, RU, UK)
R394 1-216-864-11 SHORT CHIP 0 (E32, AR)
R395 1-216-864-11 SHORT CHIP 0 (CH)
< VIBRATOR >
X101 1-813-562-21 VIBRATOR, CERAMIC 10.000MHZ (10MHz)
X201 1-781-465-21 VIBRATOR, CRYSTAL (12.288MHz)
************************************************************
MS-214 BOARD
*************
< CONNECTOR >
CN001 1-815-569-11 CONNECTOR, FFC/FPC 7P
< SWITCH >
S001 1-762-951-13 SWITCH, PUSH (DISC IN/OUT)
S002 1-762-951-13 SWITCH, PUSH (CHUCKING)
S003 1-762-951-13 SWITCH, PUSH (TRIGGER)
************************************************************
A-1249-890-A REG BOARD, COMPLETE (EXCEPT E32, AR)
A-1249-995-A REG BOARD, COMPLETE (E32, AR)
********************
< CAPACITOR >
C701 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT E32, AR)
C702 1-117-681-11 ELECT CHIP 100uF 20% 16V
(EXCEPT E32, AR)
C703 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C704 1-117-681-11 ELECT CHIP 100uF 20% 16V
C705 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C706 1-117-681-11 ELECT CHIP 100uF 20% 16V
C707 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C708 1-117-681-11 ELECT CHIP 100uF 20% 16V
C712 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT E32, AR)
C713 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C714 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C715 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C718 1-117-681-11 ELECT CHIP 100uF 20% 16V
(EXCEPT E32, AR)
C719 1-128-394-11 ELECT CHIP 220uF 20% 10V
C720 1-128-394-11 ELECT CHIP 220uF 20% 10V
C721 1-117-681-11 ELECT CHIP 100uF 20% 16V
< CONNECTOR >
CN701 1-778-795-21 PIN, CONNECTOR (PC BOARD) 9P
CN702 1-774-863-11 PIN, CONNECTOR (PC BOARD) 8P
CN708 1-785-728-21 PIN (PC BOARD), CONNECTOR 7P
* CN710 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN712 1-770-399-11 HOUSING, CONNECTOR (PC BOARD) 6P
< DIODE >
D701 8-719-404-50 DIODE MA111-TX (EXCEPT E32, AR)
D702 8-719-404-50 DIODE MA111-TX
D703 8-719-404-50 DIODE MA111-TX
D704 8-719-404-50 DIODE MA111-TX
< EARTH TERMINAL >
* ET701 1-780-408-11 TERMINAL
* ET702 1-780-408-11 TERMINAL
< IC >
IC701 6-705-308-01 IC SI-3010KM-TL (EXCEPT E32, AR)
IC702 6-705-308-01 IC SI-3010KM-TL
IC703 6-705-308-01 IC SI-3010KM-TL
IC704 6-705-308-01 IC SI-3010KM-TL
< RESISTOR >
R701 1-218-858-11 METAL CHIP 3K 0.5% 1/10W
(EXCEPT E32, AR)
R702 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
(EXCEPT E32, AR)
R703 1-216-809-11 METAL CHIP 100 5% 1/10W
(EXCEPT E32, AR)
R704 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R705 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R706 1-216-809-11 METAL CHIP 100 5% 1/10W
R707 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R708 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R709 1-216-809-11 METAL CHIP 100 5% 1/10W
R710 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R711 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R712 1-216-809-11 METAL CHIP 100 5% 1/10W
R721 1-218-885-11 METAL CHIP 39K 0.5% 1/10W
(EXCEPT E32, AR)
R722 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R723 1-218-885-11 METAL CHIP 39K 0.5% 1/10W
R724 1-218-885-11 METAL CHIP 39K 0.5% 1/10W
************************************************************
A-1249-887-A TOUCH BOARD, COMPLETE
**********************
When TOUCH board is defective, exchange the entire mounted board.
************************************************************
MS-214 REGMAIN TOUCH
