40
<LENS2>
M07
REMOTE CONTROL ON, OFF
, (OFF) Lens remote control from MSU/RCP on/off setting.
Same function as the Active button on the Zoom/
Focus Control screen of the MSU/RCP.
(OFF): When lens is not supported
CONTROL MODE ZOOM & FOCUS
, FOCUS,
FOLLOW FOCUS
ZOOM & FOCUS: Control ZOOM and FOCUS from an
MSU/RCP (control by lens demand is not
supported).
FOCUS: Control FOCUS from an MSU/RCP. ZOOM is
controlled by lens demand.
FOLLOW FOCUS: FOCUS is controlled by lens
demand, but can be adjusted (offset fine
adjustment) from an MSU/RCP. ZOOM is controlled
by lens demand.
Note
Settings other than FOLLOW FOCUS cannot be
modified when the offset is not 0 and REMOTE
CONTROL is OFF. To change settings, set REMOTE
CONTROL to ON.
FOLLOW FOCUS
OFFSET ADJUST
SENS
1, 2, 3
, 4, 5 Sets the sensitivity of superimposing the offset of the
MSU.
OFFSET CANCEL
GAIN
1, 2, 3
, 4, 5 Sets the sensitivity of canceling the offset on the
demand side.
<CALL/TALLY>
M08
FRONT TALLY ON
, OFF
BRIGHTNESS 0 to 100, 50
CALL DISABLE, ENABLE
REAR TALLY ON
, OFF
BRIGHTNESS 0 to 100, 50
<OUTPUT FORMAT>
M09 (U09)
CURRENT Display only Displays the current format.
RESOLUTION 3840×2160, 1920×1080
,
1280×720
System format settings (The selectable system
formats vary depending on camera operating software
options.)
FREQUENCY 59.94i
, 50i, 59.94P, 50P
OETF SDR
, S-LOG, HLG Camera OETF setting
LOOK ----
, Live, Mild, Natural Can be selected when OETF is not set to SDR.
For a description of Live, Mild, and Natural, see “HDR
Look Function” (page 10).
COLOR BT.709
, BT.2020 Camera color space setting
BIT DEPTH 10BIT
, 12BIT Selectable only for RGB444.
<SDI OUT>
M10 (U10)
SLOT1/2-OUT
See “SDI 1 to SDI 4 connector
settings” (page 43).
Sets the SDI 1 to SDI 4 format.
SLOT3/4-OUT
SDI MONI MAIN, VF
EMB AUDIO OFF, MIC
HD-HFR(P) 12G PID NORMAL
, 4K FIX PID setting when 12G-SDI is output in 1080P HFR
format
<GL/SYNC>
M11
IN/OUT HD-SYNC, SD-SYNC,
GENLOCK IN
SYNC-OUT Displayed when OUTPUT is set to SD-SYNC or HD-
SYNC.
V-PHASE –999 to 999, 0
H-PHASE –999 to 999, 0
MAINTENANCE
Page name
Page No.
Item Settings Description
