41
<GENLOCK>
M12
REFERENCE Synchronization status Display only
GENLOCK DISABLE, ENABLE
STATUS Display only
FORMAT
PHASE
V –1024 to 1023, 0
H –1700 to 1700, 0
<DATE>
M13
DATE/TIME 2000 to 2035/01 to 12/00 to 31
00 to 23 : 00 to 59
DATE FORMAT 1 Y/Mn/D, 2 Mn/D, 3 D/M/Y,
4 D/M, 5 M/D/Y
, 6 M/D
Y: Year
Mn: Month (numeric)
M: Month (English abbreviation)
D: Day
<BATTERY ALARM>
M14
BEFORE END 11.5
V to 17.0 V
END 11.0
V to 11.5 V
BATTERY ALARM OFF, ON
<TCP/IP SETTING>
M15
DHCP OFF, ON Enables or disables DHCP.
IP ADDRESS 0.0.0.0
to 255.255.255.255 Sets the IP address.
SUBNET MASK 0.0.0.0
to 255.255.255.255 Sets the subnet mask.
DEFAULT GATEWAY 0.0.0.0
to 255.255.255.255 Sets the default gateway.
SET Execute using ENTER. When “SET OK?” is displayed, execute using ENTER
again to apply the changes on the page.
MAC ADDRESS MAC address Displayed when DHCP is ON.
<CNS SETTINGS>
M16
CNS MODE LEGACY
, BRIDGE, MCS Select the network connection method.
See “CNS SETTINGS (MAINTENANCE menu)”
(page 11).
CCU NO Default setting is 1 1 to 96 when CNS MODE is set to MCS.
MASTER IP ADDRESS 0.0.0.0
to 255.255.255.255
SET Execute using ENTER. When “SET OK?” is displayed, execute using ENTER
again to apply the changes on the page.
<NETWORK RESET>
M17
NETWORK ALL RESET Execute using ENTER. When “RESET OK?” is displayed, execute using
ENTER again to restore all settings in MAINTENANCE
menu items M15 to M17 to the factory default settings.
<TSL UMD>
M18
TSL UMD DISABLE
, ENABLE Enables/disables IP Tally using TSL UMD V5.0.
PORT NUMBER 8900
Displays the UDP port number for TSL UMD
connections.
PACKET STATUS NOT RECEIVED
, RECEIVED Displays the receive status of TSL UMD packets.
When received, IDs and Red/Green on/off status is
displayed.
Up to five IDs can be displayed. “AND MORE” is
displayed if there are more than five.
<SIMPLE
PROTOCOL>
M19
TRANSPORT
CONVERTER MODE
ENABLE, DISABLE
Enables camera control of devices, for example, that
operate on networks with high latency.
This enables the transport conversion mode.
When set to ENABLE, CNS MODE is set to LEGACY
(fixed).
PORT REMOTE(RS-422A)
, LAN Sets the port to enable for transport conversion mode.
BAUDRATE 9.6kbps to 843.75kbps,
115.2kbps
Displayed only when PORT is set to REMOTE(RS-
422A).
TARGET IP
ADDRESS
0.0.0.0
to 255.255.255.255 Displayed only when PORT is set to LAN.
TCP PORT 0
to 65535 Displayed only when PORT is set to LAN.
MAINTENANCE
Page name
Page No.
Item Settings Description
