Chapter 10
Setup Menus
Chapter 10
Setup Menus 10-31
Item number Item name Settings
934
CROSS COLOR (DC)
Carry out the down-converter cross color adjustment.
0 to 8 to 15
935 DETAIL GAIN (DC) Carry out the down-converter image enhancer adjustment. Adjust the sharpness
of edge emphasis.
0 to 20H to 7FH
936 LIMITER (DC) Carry out the down-converter image enhancer adjustment.
Adjust the maximum detail level added to emphasize the original signal.
0 to 20H to 3FH
937
CRISP THRESHOLD (DC) Carry out the down-converter image enhancer adjustment. Set the threshold
amplitude at which low amplitude signals are not emphasized.
0 to FH
938
LEVEL DEPEND
THRESHOLD (DC)
Carry out the down-converter image enhancer adjustment. Set the luminance
range for edge enhancement.
0 to 8 to FH
939
H DETAIL FREQUENCY
(DC)
Carry out the down-converter image enhancer adjustment. Set the central
frequency for edge enhancement.
2.6MHz to 3.4MHz to 3.9MHz to 4.6MHz
940
H/V RATIO (DC)
Carry out the down-converter image enhancer adjustment. Set the horizontal/
vertical ratio for edge enhancement.
0 to 3 to 7
941
GAMMA LEVEL (DC) Carry out the down-converter image enhancer adjustment. Adjust the slope of the
correction curve.
0 to 80H to 100H
918 SLOW PROCESS MODE Switch the filter for increasing the vertical resolution during slow-motion playback
on or off.
ON: Increase the vertical resolution in slow-motion playback.
OFF : Do not increase the vertical resolution in slow-motion playback.
930 CONVERTER MODE (DC) Select the down-converter mode.
EDGE-CROP : Select the edge-crop mode.
LETTER BOX: Select the letter box mode.
SQUEEZE: Select the squeeze mode.
931 LETTER BOX MODE (DC) Select the aspect ratio of the down-converter output when menu item 930 is set to
LETTER BOX.
16:9 : Set the aspect ratio of the HD-SD converter output to 16:9.
14:9: Set the aspect ratio of the HD-SD converter output to 14:9.
13:9: Set the aspect ratio of the HD-SD converter output to 13:9.
932
H CROP POSITION (DC) Adjust the “H-crop” (the horizontal position when cropping in the edge crop mode)
of the up/down converter output when menu item 930 is set to EDGE-CROP.
–120 to 0 to 120
(Continued)
Menu items in the range 900 to 999, relating to digital processing (continued)
