Sony HMD-A400 - Timing Specification

HMD-A400
– 4 –
TIMING SPECIFICATION
MODE AT PRODUCTION MODE 1 MODE 2 MODE 3 MODE 4 MODE 5
RESOLUTION 640 X 480 640 X 480 720 X 400 800 X 600 832 X 624
CLOCK 25.175 MHz 36.000 MHz 28.321 MHz 56.250 MHz 57.283 MHz
— HORIZONTAL —
H-FREQ 31.469 kHz 43.269 kHz 31.468 kHz 53.674 kHz 49.725 kHz
usec usec usec usec usec
H. TOTAL 31.778 23.111 31.779 18.631 20.111
H. BLK 6.356 5.333 6.356 4.409 5.586
H. FP 0.636 1.556 0.636 0.569 0.559
H. SYNC 3.813 1.556 3.813 1.138 1.117
H. BP 1.907 2.222 1.907 2.702 3.910
H. ACTIV 25.422 17.778 25.423 14.222 14.524
— VERTICAL —
V. FREQ(HZ) 59.940 Hz 85.008 Hz 70.084 Hz 85.061 Hz 74.550 Hz
lines lines lines lines lines
V. TOTAL 525 509 449 631 667
V. BLK 45 29 49 31 43
V. FP 10 1 12 1 1
V. SYNC 2 3 2 3 3
V. BP 33 25 35 27 39
V. ACTIV 480 480 400 600 624
— SYNC —
INT(G) NO NO NO NO NO
EXT(H/V)/POLARITY YES N/N YES N/N YES N/P YES N/P YES N/N
EXT(CS)/POLARITY NO NO NO NO NO
INT/NON INT NON INT NON INT NON INT NON INT NON INT
MODE AT PRODUCTION MODE 6 MODE 7 MODE 8 MODE 9
RESOLUTION 1024 X 768 1152 X 870 1280 X 1024 1600 X 1200
CLOCK 94.500 MHz 100.000 MHz 135.000 MHz 162.000 MHz
— HORIZONTAL —
H-FREQ 68.677 kHz 68.681 kHz 79.976 kHz 75.000 kHz
usec usec usec usec
H. TOTAL 14.561 14.560 12.504 13.333
H. BLK 3.725 3.040 3.022 3.457
H. FP 0.508 0.320 0.119 0.395
H. SYNC 1.016 1.280 1.067 1.185
H. BP 2.201 1.440 1.837 1.877
H. ACTIV 10.836 11.520 9.481 9.877
— VERTICAL —
V. FREQ(HZ) 84.997 Hz 75.062 Hz 75.025 Hz 60.000 Hz
lines lines lines lines
V. TOTAL 808 915 1066 1250
V. BLK 40 45 42 50
V. FP 1 3 1 1
V. SYNC 3 3 2 3
V. BP 36 39 38 46
V. ACTIV 768 870 1024 1200
— SYNC —
INT(G) NO NO NO NO
EXT(H/V)/POLARITY YES P/P YES N/N YES P/P YES P/P
EXT(CS)/POLARITY NO NO NO NO
INT/NON INT NON INT NON INT NON INT NON INT
2001.2.23 VER.
