30
HT-BE1/SA-WBE1/SS-BE1
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
•Abbreviation
CND : Canadian model
SP : Singapore model
MY : Malaysia model
MX : Mexican model
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
1-685-234-12 DISPLAY BOARD
**************
< CAPACITOR >
C701 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C703 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C705 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C706 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C707 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C708 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN701 1-784-736-11 CONNECTOR, FFC 14P
CN702 1-568-935-11 PIN, CONNECTOR 8P
< DIODE >
D702 6-500-076-01 LED SLI-343YC (LCD BACK LIGHT)
D703 6-500-076-01 LED SLI-343YC (LCD BACK LIGHT)
D704 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC701 8-759-573-02 IC BU9735K-E2
IC702 8-759-826-34 IC NJL74H400A
< LIQUID CRYSTAL DISPLAY >
LCD701 1-804-673-11 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R701 1-216-845-11 METAL CHIP 100K 5% 1/10W
R702 1-216-853-11 METAL CHIP 470K 5% 1/10W
R709 1-216-809-11 METAL CHIP 100 5% 1/10W
R710 1-216-809-11 METAL CHIP 100 5% 1/10W
R712 1-216-809-11 METAL CHIP 100 5% 1/10W
R713 1-216-809-11 METAL CHIP 100 5% 1/10W
R714 1-216-845-11 METAL CHIP 100K 5% 1/10W
*************************************************************
1-685-235-12 JACK BOARD
***********
< CAPACITOR >
C539 1-164-159-21 CERAMIC 0.1uF 50V
C597 1-162-282-31 CERAMIC 100PF 10% 50V
C598 1-162-282-31 CERAMIC 100PF 10% 50V
C599 1-164-159-21 CERAMIC 0.1uF 50V
< IC >
IC503 8-749-923-05 IC TORX178B (DIGITAL IN OPTICAL)
< CONNECTOR >
J501 1-815-194-11 CONNECTOR, USB (B) (USB)
< JACK >
J502 1-816-609-11 JACK, PIN 3P (AUDIO IN, DIGITAL IN COAXIAL)
< TERMINAL BOARD >
J503 1-694-656-11 TERMINAL BOARD (6CH) (SPEAKER)
*************************************************************
1-685-236-12 KEY BOARD
**********
< CONNECTOR >
CNP701 1-775-377-61 LEAD (WITH CONNECTOR) 8P
< DIODE >
D701 8-719-067-82 LED SML-020MLTT86 (?/1)
< TRANSISTOR >
Q701 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R703 1-216-809-11 METAL CHIP 100 5% 1/10W
R704 1-216-813-11 METAL CHIP 220 5% 1/10W
R705 1-216-809-11 METAL CHIP 100 5% 1/10W
R706 1-216-809-11 METAL CHIP 100 5% 1/10W
R707 1-216-809-11 METAL CHIP 100 5% 1/10W
R708 1-216-833-11 METAL CHIP 10K 5% 1/10W
R711 1-216-809-11 METAL CHIP 100 5% 1/10W
R715 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R716 1-216-837-11 METAL CHIP 22K 5% 1/10W
< SWITCHING REGULATOR >
RE701 1-477-255-11 REGULATOR, SWITCHING (VOL/SELECT)
DISPLAY JACK
KEY
