1010
HT-BE1/SA-WBE1/SS-BE1
8. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
•Abbreviation
CND : Canadian model
MX : Mexican model
SP : Singapore model
MY : Malaysia model
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
A-4728-814-A MAIN BOARD, COMPLETE (US,CND,MX)
A-4728-816-A MAIN BOARD, COMPLETE (AEP,UK,SP,MY)
*********************
1-533-313-11 HOLDER, FUSE
< CAPACITOR >
C301 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C302 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C303 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C304 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C305 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C306 1-124-234-00 ELECT 22uF 20% 16V
C307 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C308 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C309 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C310 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C311 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C312 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C313 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C314 1-126-947-11 ELECT 47uF 20% 35V
C315 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C316 1-126-934-11 ELECT 220uF 20% 16V
C317 1-136-165-00 FILM 0.1uF 5% 50V
C319 1-136-165-00 FILM 0.1uF 5% 50V
C320 1-136-165-00 FILM 0.1uF 5% 50V
C321 1-136-165-00 FILM 0.1uF 5% 50V
C323 1-136-165-00 FILM 0.1uF 5% 50V
C325 1-136-165-00 FILM 0.1uF 5% 50V
C326 1-136-165-00 FILM 0.1uF 5% 50V
C328 1-136-165-00 FILM 0.1uF 5% 50V
C329 1-124-465-00 ELECT 0.47uF 20% 50V
C332 1-131-700-31 FILM 0.47uF 5% 50V
C334 1-136-165-00 FILM 0.1uF 5% 50V
C336 1-131-694-31 FILM 0.15uF 5% 50V
C340 1-136-165-00 FILM 0.1uF 5% 50V
C341 1-131-694-31 FILM 0.15uF 5% 50V
C344 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
C345 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C346 1-124-234-00 ELECT 22uF 20% 16V
C347 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C348 1-124-234-00 ELECT 22uF 20% 16V
C349 1-124-234-00 ELECT 22uF 20% 16V
C350 1-126-947-11 ELECT 47uF 20% 35V
C351 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C354 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C355 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C356 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C358 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C359 1-124-234-00 ELECT 22uF 20% 16V
C362 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C363 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C364 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C365 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C366 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C367 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C371 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C372 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C373 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C374 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C375 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C378 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C379 1-126-960-11 ELECT 1uF 20% 50V
C380 1-126-960-11 ELECT 1uF 20% 50V
C381 1-126-768-11 ELECT 2200uF 20% 16V
(AEP,UK,SP,MY)
C381 1-126-953-11 ELECT 2200uF 20% 35V
(US,CND,MX)
C382 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C383 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C384 1-124-465-00 ELECT 0.47uF 20% 50V
C385 1-124-465-00 ELECT 0.47uF 20% 50V
C386 1-124-465-00 ELECT 0.47uF 20% 50V
C387 1-126-960-11 ELECT 1uF 20% 50V
C388 1-126-947-11 ELECT 47uF 20% 35V
C389 1-124-465-00 ELECT 0.47uF 20% 50V
C390 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C391 1-126-947-11 ELECT 47uF 20% 35V
C392 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C393 1-124-465-00 ELECT 0.47uF 20% 50V
C394 1-124-465-00 ELECT 0.47uF 20% 50V
C395 1-124-465-00 ELECT 0.47uF 20% 50V
C396 1-124-465-00 ELECT 0.47uF 20% 50V
C397 1-126-960-11 ELECT 1uF 20% 50V
C398 1-126-947-11 ELECT 47uF 20% 35V
C399 1-124-465-00 ELECT 0.47uF 20% 50V
C421 1-126-964-11 ELECT 10uF 20% 50V
C422 1-126-964-11 ELECT 10uF 20% 50V
C423 1-126-964-11 ELECT 10uF 20% 50V
C424 1-126-964-11 ELECT 10uF 20% 50V
MAIN
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C425 1-126-964-11 ELECT 10uF 20% 50V
C426 1-126-964-11 ELECT 10uF 20% 50V
C427 1-126-964-11 ELECT 10uF 20% 50V
C428 1-126-960-11 ELECT 1uF 20% 50V
C431 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C432 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C433 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C434 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C435 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C436 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C437 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C438 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C439 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C440 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C441 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C442 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C443 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C444 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C503 1-126-964-11 ELECT 10uF 20% 50V
C504 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C505 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C506 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C507 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C508 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C509 1-126-964-11 ELECT 10uF 20% 50V
C510 1-126-964-11 ELECT 10uF 20% 50V
C511 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C512 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C513 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C514 1-126-964-11 ELECT 10uF 20% 50V
C515 1-126-964-11 ELECT 10uF 20% 50V
C517 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C518 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C519 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C520 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C521 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C522 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C523 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C524 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C525 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C526 1-126-964-11 ELECT 10uF 20% 50V
C527 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C528 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C529 1-126-960-11 ELECT 1uF 20% 50V
C530 1-126-960-11 ELECT 1uF 20% 50V
C531 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C532 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C533 1-126-153-11 ELECT 22uF 20% 6.3V
C534 1-126-960-11 ELECT 1uF 20% 50V
C535 1-126-964-11 ELECT 10uF 20% 50V
C536 1-126-947-11 ELECT 47uF 20% 35V
C537 1-126-153-11 ELECT 22uF 20% 6.3V
C538 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C540 1-126-964-11 ELECT 10uF 20% 50V
C541 1-126-964-11 ELECT 10uF 20% 50V
C542 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C543 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C544 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C545 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C558 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
C601 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C602 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C603 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C604 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C605 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C606 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C607 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C608 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C609 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C801 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C802 1-104-662-11 ELECT 22uF 20% 25V
C803 1-126-923-11 ELECT 220uF 20% 10V
C804 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C806 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C807 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C808 1-104-905-11 DOUBLE LAYERS 0.22F 5.5V
C809 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C810 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C811 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
C812 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C813 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C814 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C815 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C817 1-126-960-11 ELECT 1uF 20% 50V
C818 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C819 1-126-960-11 ELECT 1uF 20% 50V
C822 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C823 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C824 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C825 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C826 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C827 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C831 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
C832 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C833 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C834 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C835 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
C836 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C837 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C838 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C839 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C840 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C841 1-126-153-11 ELECT 22uF 20% 6.3V
C842 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C843 1-124-434-00 ELECT 220uF 20% 4V
C844 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
C845 1-104-662-11 ELECT 22uF 20% 25V
C846 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C847 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C849 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C850 1-126-153-11 ELECT 22uF 20% 6.3V
C851 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C852 1-126-153-11 ELECT 22uF 20% 6.3V
C853 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
MAIN
