– POWER Board –
IC930 STR-Y6735 (US, Canadian and Taiwan models)
IC930 STR-Y6766 (Except US, Canadian and Taiwan models)
– DISPLAY Board –
IC806 MM3411A33URE
VOUT
3
CE 1
GND
2
VDD
4
+
–
VOLTAGE
REFERENCE
CURRENT
LIMIT
BIAS
D/ST 1
S/OCP
2
VCC 3
GND 4
BD
6
FB/OLP
5
STARTUP
LOGIC
DRIVER
LATCH
OVERCURRENT
PROTECTION/
BOTTOM-SKIP
UNDER VOLTAGE
LOCK OUT/
REGULATOR/
CONSTANT CURRENT
FEEDBACK/
STANDBY
OVERLOAD
PROTECTION
BOTTOM
DETECTION
NF 7
OSCILLAOTR
