Pin No. Pin Name I/O Description
60 BCLK_OUT O Bit clock signal output to the stream processor and RF modulator
61 LRCLK_OUT O L/R sampling clock signal output to the stream processor and RF modulator
62 SBL/SBR_IN I Audio signal (for surround back L-ch/R-ch) input from the digital audio interface receiver
63 L/R_IN I Audio signal (for front L-ch/R-ch) input from the digital audio interface receiver
64 VDD_INT - Power supply terminal (+1.1V) (for core)
65 DIR_IN I Audio signal input from the digital audio interface receiver
66, 67 VDD_INT - Power supply terminal (+1.1V) (for core)
68 GND - Ground terminal
69 THD_M O Thermal detection signal output terminal Not used
70 THD_P I Thermal detection signal input terminal Not used
71 VDD_THD - Not used
72 to 76 VDD_INT - Power supply terminal (+1.1V) (for core)
77 FLAG0 O Interrupt request signal output to the system controller
78, 79 VDD_INT - Power supply terminal (+1.1V) (for core)
80 FLAG1 I Error detection signal input terminal “L”: error
81 FLAG2 I Audio setting signal input terminal “L”: LPCM audio, “H”: HBR audio
82 FLAG3 - Not used
83 MLBCLK - Not used
84 MLBDAT - Not used
85 MLBDO - Not used
86 VDD_EXT - Power supply terminal (+3.3V) (for I/O)
87 MLBSIG - Not used
88 VDD_INT - Power supply terminal (+1.1V) (for core)
89 MLBSO - Not used
90 TRST I Test reset signal input terminal (for JTAG) Not used
91 EMU O Emulation status signal output terminal Not used
92 TDO O Test data output terminal (for JTAG) Not used
93 VDD_EXT - Power supply terminal (+3.3V) (for I/O)
94 VDD_INT - Power supply terminal (+1.1V) (for core)
95 TDI I Test data input terminal (for JTAG) Not used
96 TCK I Test clock signal input terminal (for JTAG) Not used
97 VDD_INT - Power supply terminal (+1.1V) (for core)
98 RESET I Reset signal input from the system controller “L”: reset
99 TMS I Test mode selection signal input terminal (for JTAG) Not used
100 VDD_INT - Power supply terminal (+1.1V) (for core)
