56
GB
Specifications
Amplifier section
Models of area code SP, TH1
Power Output
Stereo mode (rated) (6 ohms, 1 kHz, THD 1%)
70 W + 70 W
1)
60 W + 60 W
2)
Surround mode
3)
(reference) (6 ohms, 1 kHz,
THD 10%)
RMS output
FRONT: 100 W per channel
1)
90 W per channel
2)
CENTER: 100 W
1)
90 W
2)
SURROUND: 100 W per channel
1)
90 W per channel
2)
Surround mode
3)
(reference) (10 ohms,
100 Hz, THD 10%)
SUBWOOFER: 60 W per channel
1)
50 W per channel
2)
1)
Measured under the following conditions:
2)
Measured under the following conditions:
3)
Reference power output for front, center, surround
speakers and subwoofer. Depending on the sound
field settings and the source, there may be no
sound output.
Inputs
Analog Sensitivity: 800 mV/
50 kohms
Digital (Coaxial) Impedance: 75 ohms
Tone
Gain levels ±6 dB, 1 dB step
Reproduction frequency range:
28 – 20,000 Hz
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency
10.7 MHz
AM tuner section
Tuning range
Models of area code SP, TH1
With 9-kHz tuning scale:
531 – 1,602 kHz
Antenna Loop antenna
Intermediate frequency
450 kHz
General
Power requirements
Power consumption
Power consumption (during standby mode)
0.3 W
Dimensions (width/height/depth) (Approx.)
430 × 145 × 306 mm
including projecting parts
and controls
Mass (Approx.) 7.6 kg
Area code Power requirements
SP, TH1 230 V AC, 50 Hz
Area code Power requirements
TH1 220 V AC, 50 Hz
Area code Power requirements
SP 230-240 V AC, 50/60 Hz
TH1 220-230 V AC, 50/60 Hz
Area code Power consumption
SP, TH1 220 W
