Sony HT-NT5 Service Manual

HT-NT5
9
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-28. POWER BOARD SERVICE POSITION
(Page 28)
2-27. MB-1509 BOARD SERVICE POSITION
(Page 28)
2-18. POWER CORD (AC1)
(Page 22)
2-19. POWER BOARD
(Page 22)
2-2. TOP CABINET BLOCK
(Page 10)
2-3. TOUCH BOARD
(Page 11)
2-4. DISPLAY BOARD BLOCK
(Page 11)
2-8. CONNECTION CABLE WITH SPEAKER (WOOFER)
(Page 14)
2-5. SIRCS BOARD
(Page 12)
2-6. DISPLAY BOARD
(Page 12)
2-7. ORGANIC EL INDICATOR
ELEMENT (OLED1)
(Page 13)
2-14. BTW (WIFI) BOARD
(Page 19)
2-13. NFC BOARD
(Page 18)
2-21. USB-CHUKEI BOARD
(Page 23)
2-23. REPEATER BOARD
(Page 25)
2-11. RF MODULATOR BLOCK
(Page 17)
2-16. WLAN/BT COMBO CARD (WIFI1)-2
(Page 21)
2-15. WLAN/BT COMBO CARD (WIFI1)-1
(Page 20)
2-17. INSULATOR (TOP)
(Page 21)
2-9. CONNECTION CABLE WITH SPEAKER (TWEETER)
(Page 15)
2-10. LOUDSPEAKER (WOOFER) (SP1, SP2),
LOUDSPEAKER (TWEETER) (SP3, SP4, SP5, SP6)
(Page 16)
2-12. RF MODULATOR (RF1)
(Page 17)
2-22. BTW (BT) BOARD
(Page 24)
2-20. AMP BOARD
(Page 23)
2-24. MB-1509 BOARD-1
(Page 25)
2-25. MB-1509 BOARD-2
(Page 26)
2-26. BOTTOM CHASSIS BLOCK
(Page 27)

Sony HT-NT5 Specifications

General

Type	Soundbar
Channels	2.1
Subwoofer	Wireless
HDMI Inputs	3
HDMI Outputs	1
Bluetooth	Yes
Wi-Fi	Yes
Dolby Atmos	No
DTS:X	No
NFC	Yes
USB	Yes
Ethernet	Yes
High-Resolution Audio	Yes
Optical Input	Yes
Audio Decoding	Dolby Digital, DTS
Weight	3.2 kg (Main Unit)
