HT-ST7
6
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-3. PANEL (REAR L) BLOCK, PANEL (REAR R)
(Page 7)
2-6. BRACKET (BOTTOM) BLOCK
(Page 9)
2-4. BRACKET (ARM A/B) ASSY, FUSE (F502)
(Page 8)
2-5. BRACKET (AIR) ASSY
(Page 8)
2-7. POWER CORD (AC1)
(Page 10)
2-8. CHASSIS BLOCK
(Page 11)
2-20. LOUDSPEAKER (6.5 cm)
(SP3) (L-ch)
(Page 19)
2-18. BLUETOOTH MODULE (BT1)
(Page 18)
2-17. RC-S801/A (NFC1)
(Page 17)
2-19. FRONT SPEAKER (L) BLOCK
(Page 19)
2-23. FRONT SPEAKER (R) BLOCK
(Page 22)
2-21. LOUDSPEAKER (2 cm)
(SP1) (L-ch)
(Page 20)
2-22. CABLE WITH CONNECTOR
(SPC1) (L-ch)
(Page 21)
2-15. CABLE WITH CONNECTOR
(SPC3)
(Page 16)
2-16. CABLE WITH CONNECTOR
(SPC4)
(Page 16)
2-25. LOUDSPEAKER (6.5 cm)
(SP4) (R-ch)
(Page 23)
2-26. LOUDSPEAKER (2 cm)
(SP2) (R-ch)
(Page 24)
2-27. CABLE WITH CONNECTOR
(SPC2) (R-ch)
(Page 25)
2-29. FLEXIBLE FLAT CABLE
(14P) (FFC1)
(Page 26)
2-28. KEY BOARD
(Page 26)
2-9. POWER BOARD
(Page 12)
2-10. AMP BOARD
(Page 12)
2-11. IO BOARD
(Page 13)
2-12. MAIN BOARD
(Page 13)
2-14. LOUDSPEAKER (6.5 cm)
(SP5, SP6, SP7, SP8, SP9)
(Page 15)
2-13. CENTER SPEAKER BLOCK
(Page 14)
2-24. DISPLAY BOARD
(Page 23)
2-2. PANEL (L/R) ASSY
(Page 7)
Note:
When disassembling the unit, start working after removing the grill frame always first.
To Next Page
