5-7
Ref. No. Part No. Description Ref. No. Part No. Description
HVR-DR60
HD-035
C306 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C307 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C308 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C309 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C310 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C311 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C312 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C313 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C314 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C315 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C401 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C402 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C403 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C404 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C405 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C406 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C407 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C408 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C409 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C410 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C411 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C412 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C413 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C414 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C415 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C416 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C417 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C418 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C504 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C510 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C517 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C522 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C527 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C532 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C536 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C537 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C538 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C539 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C543 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C545 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C546 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C548 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C549 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C550 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C551 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C552 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C553 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C554 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C555 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C556 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C557 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C558 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C559 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C560 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C561 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C562 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C563 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C564 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C565 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C566 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN101 1-691-550-11 PIN, CONNECTOR (1.5MM) (SMD) 3P
CN102 1-573-290-21 PIN, CONNECTOR (1.5MM) (SMD) 4P
* CN201 1-816-648-51 FFC/FPC CONNECTOR (LIF) 20P
* CN203 1-691-358-51 CONNECTOR, FFC/FPC (ZIF) 20P
CN401 1-815-334-51 CONNECTOR, FPC (ZIF) 51P
CN402 1-817-382-11 CONNECTOR, I-LINK (6P)
< DIODE >
D109 6-501-124-01 DIODE RSX101VA-30TR
0 D111 6-501-272-01 DIODE RB520CS-30T2R
D113 6-501-124-01 DIODE RSX101VA-30TR
D115 8-719-158-49 DIODE RD12SB2
D116 8-719-158-49 DIODE RD12SB2
0 D119 6-501-272-01 DIODE RB520CS-30T2R
D123 8-719-056-54 DIODE MAZS068008SO
< FUSE >
0 F101 1-576-406-11 FUSE (1.4A/32V)
0 F102 1-576-406-11 FUSE (1.4A/32V)
< FERRITE BEAD >
FB102 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB103 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB104 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB106 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB108 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB109 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB112 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
* FB113 1-481-196-21 FERRITE, EMI (SMD) (3216)
FB201 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB301 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB401 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB402 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB403 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB404 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB405 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB406 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB501 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB502 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB504 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB505 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB506 1-400-331-11 FERRITE, EMI (SMD) (1005)
< FLUORESCENT INDICATOR TUBE >
FL401 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL402 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL403 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC >
0 IC101 6-707-357-01 IC LTC3728LXCUH#TR-R5
• Refer to page 5-1 for mark 0.
