74 Appendix
Appendix
Specifications
System
Video/Audio recording/playing Head System
Rotating dual-head helical scan
Audio recording format (HDV)
MPEG-1 Audio Layer2
16-bit 48 kHz (stereo)
Transfer rate 384 kbps
Audio recording format (DVCAM (DV))
12-bit Fs32K (Channel 1/2,
Channel 3/4)
16-bit Fs48K (Channel 1/2)
Video signal 1080/60i, NTSC color,
EIA standard system
1080/50i, PAL color,
CCIR standard system
Usable cassettes Standard DVCAM cassettes with
mark
Mini DVCAM cassettes with
mark
Tape speed (HDV)
Approx. 18.812 mm/s
Tape speed (DVCAM)
Approx. 28.218 mm/s
Tape speed (DV) Approx. 18.812 mm/s
Recording/playback time (HDV)
Approx. 276 min
(using PHDV-276DM)
Approx. 63 min
(using PHDVM-63DM)
Recording/playback time (DVCAM)
Approx. 184 min
(using PHDV-276DM)
Approx. 41 min
(using PHDVM-63DM)
Recording/playback time (DV SP)
Approx. 276 min
(using PHDV-276DM)
Approx. 63 min
(using PHDVM-63DM)
AUDIO jacks
IN Pin jack: –10 dBu
Impedance: Minimum 10 kΩ
(kilo ohms), unbalanced
Maximum input level:
+16 dBu (approx. 5 Vrms)
60i system
+14 dBu (approx. 4 Vrms)
50i system
OUT Pin jack
Impedance: Maximum 1 kΩ
(kilo ohms)
Output level: 47 kΩ
(kilo ohms) loading, unbalanced
–10 dBu (= full bit –20 dB)
60i system
–10 dBu (= full bit –18 dB)
50i system
VIDEO jacks
IN/OUT Pin jack, unbalanced
1.0 Vp-p
(75 Ω (ohms), sync negative)
Sync signal:
0.286 Vp-p (60i/NTSC)
0.3 Vp-p (50i/PAL)
Burst signal:
0.286 Vp-p (60i/NTSC)
0.3 Vp-p (50i/PAL)
S VIDEO jacks
IN/OUT Mini DIN 4-pin, unbalanced
Luminance signal:
1.0 Vp-p
(75 Ω (ohms), sync negative)
Sync signal:
0.286 Vp-p (60i/NTSC)
0.3 Vp-p (50i/PAL)
Chrominance signal:
0.286 Vp-p (60i/NTSC)
(burst, 75 Ω (ohms))
0.3 Vp-p (50i/PAL)
(burst, 75 Ω (ohms))
