HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
2-23
Ref. No. Part No. Description Ref. No. Part No. Description
Ref. No. Part No. Description
Ref. No. Part No. Description
< RESISTOR >
R2502 1-217-806-11 METAL CHIP 1 5% 1/8W
R2503 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2504 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2505 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2506 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2509 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2510 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2513 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R2514 1-208-889-11 METAL CHIP 1.2K 0.5% 1/16W
R2515 1-218-975-11 METAL CHIP 68K 5% 1/16W
R2516 1-218-973-11 METAL CHIP 47K 5% 1/16W
R2517 1-218-973-11 METAL CHIP 47K 5% 1/16W
R2519 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2520 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2521 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2523 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R2524 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2525 1-218-975-11 METAL CHIP 68K 5% 1/16W
R2526 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R2531 1-218-941-81 METAL CHIP 100 5% 1/16W
R2532 1-218-941-81 METAL CHIP 100 5% 1/16W
R2533 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2534 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2535 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2536 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
A-1752-121-A TC-001 BOARD, COMPLETE
**********************
< CAPACITOR >
C6503 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6506 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6510 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6511 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C6514 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C6519 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
< CONNECTOR >
CN6501 1-816-655-61 CONNECTOR, FFC/FPC 8P
CN6502 1-793-446-11 JACK, PIN 1P
CN6503 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
< DIODE >
D6501 8-719-069-29 DIODE RB520S-30FJTE61
D6502 8-719-069-29 DIODE RB520S-30FJTE61
< IC >
IC6501 6-710-786-01 IC TC7SH125FU (T5RSOYF)
IC6504 8-759-494-88 IC TC75S56F (TE85R)
IC6506 8-759-678-15 IC TLV2231CDBVR
< RESISTOR >
R6512 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R6514 1-218-989-11 METAL CHIP 1M 5% 1/16W
R6516 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R6517 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6519 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R6520 1-218-969-11 METAL CHIP 22K 5% 1/16W
R6523 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R6524 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R6525 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R6526 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R6529 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R6534 1-218-929-11 METAL CHIP 10 5% 1/16W
R6536 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R6540 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
A-1752-126-A TS-157 BOARD, COMPLETE
**********************
< CONNECTOR >
CN9001 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
< SWITCH >
S9001 1-786-043-21 SWITCH, SLIDE
A-1758-578-A VC-582 BOARD, COMPLETE (SERVICE)
*******************************
(CN4402, IC2001 and IC2601 are not supplied, but they are included in VC-582
complete board (service).)
< CAPACITOR >
C1007 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1009 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1010 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1011 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1012 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1013 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1214 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1215 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1216 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1217 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1218 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1219 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1220 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1221 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1222 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1223 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1224 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1225 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1401 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1402 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1403 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1404 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1405 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1406 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1407 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1408 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1409 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1410 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1411 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1412 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1413 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1414 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1415 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1416 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1417 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C1418 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C1419 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C1420 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1421 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C1422 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C1423 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C1424 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C1431 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1432 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1440 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1441 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C1443 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1444 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1445 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1446 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C1447 1-164-854-11 CERAMIC CHIP 15PF 5% 50V
C1448 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1449 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1601 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1602 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1603 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1604 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1605 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C1606 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2001 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2003 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2004 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C2005 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C2007 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2008 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2012 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2013 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2014 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2015 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2016 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2017 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2018 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2019 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2020 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2021 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C2022 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C2023 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C2024 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2025 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2026 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2028 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2029 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2030 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2032 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2033 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2034 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2201 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C2202 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2203 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2204 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C2205 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2206 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2207 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2208 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2209 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C2301 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2304 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2305 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2306 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2307 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
* C2308 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2309 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2310 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2311 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2312 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2313 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2314 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
* C2315 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
* C2316 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2317 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2318 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
* C2319 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2504 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2507 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2508 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2509 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C2510 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2511 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2512 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2513 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2514 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2515 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2516 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2517 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2518 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2519 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2520 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
* C2521 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
* C2522 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2603 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2604 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2605 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2606 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2607 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2608 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2609 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C2610 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2611 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2612 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2805 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2809 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C2810 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C2811 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C2814 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2816 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2817 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2822 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
PI-030 TC-001 TS-157 VC-582
