HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U

2-22

Ref. No. Part No. Description Ref. No. Part No. Description

Ref. No. Part No. Description

R5020 1-218-941-81 METAL CHIP 100 5% 1/16W

R5021 1-218-446-11 METAL CHIP 1 5% 1/10W

R5022 1-218-938-11 METAL CHIP 56 5% 1/16W

R5024 1-218-941-81 METAL CHIP 100 5% 1/16W

A-1752-120-A MS-424 BOARD, COMPLETE

**********************

< CAPACITOR >

C5518 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V

C5519 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V

C5520 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C5521 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C5522 1-165-908-11 CERAMIC CHIP 1uF 10% 10V

C5523 1-165-908-11 CERAMIC CHIP 1uF 10% 10V

C5524 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C5525 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C5526 1-165-908-11 CERAMIC CHIP 1uF 10% 10V

C5527 1-165-908-11 CERAMIC CHIP 1uF 10% 10V

< CONNECTOR >

* CN5501 1-821-501-11 CONNECTOR, FPC (ZIF) 51P

CN5502 1-822-837-21 CARD CONNECTOR

CN5503 1-822-837-21 CARD CONNECTOR

< DIODE >

D5501 6-502-193-01 DIODE SML-D12V8WT86SN

D5502 6-500-594-01 DIODE CL-196SYG-CD-T

D5503 6-502-193-01 DIODE SML-D12V8WT86SN

D5504 6-500-594-01 DIODE CL-196SYG-CD-T

* D5505 6-502-947-01 DIODE RB751CS-40T2R

* D5506 6-502-947-01 DIODE RB751CS-40T2R

* D5507 6-502-947-01 DIODE RB751CS-40T2R

* D5508 6-502-947-01 DIODE RB751CS-40T2R

* D5509 6-502-947-01 DIODE RB751CS-40T2R

< FERRITE BEAD >

FB5501 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5502 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5503 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5504 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5505 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5506 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5507 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5508 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5509 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5510 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5511 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

FB5512 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)

< IC >

IC5501 8-759-058-62 IC TC7S08FU (TE85R)

IC5502 8-759-058-62 IC TC7S08FU (TE85R)

* IC5508 6-712-135-01 IC R1173H001D-T1-F

* IC5509 6-714-502-01 IC BD2224G-TR

* IC5510 6-714-502-01 IC BD2224G-TR

* IC5511 6-714-502-01 IC BD2224G-TR

* IC5512 6-714-502-01 IC BD2224G-TR

< TRANSISTOR >

Q5501 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)

Q5502 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)

< RESISTOR >

R5507 1-218-954-11 METAL CHIP 1.2K 5% 1/16W

R5508 1-218-945-11 METAL CHIP 220 5% 1/16W

R5509 1-218-945-11 METAL CHIP 220 5% 1/16W

R5510 1-218-945-11 METAL CHIP 220 5% 1/16W

R5511 1-218-945-11 METAL CHIP 220 5% 1/16W

R5522 1-218-990-81 SHORT CHIP 0

R5523 1-218-941-81 METAL CHIP 100 5% 1/16W

R5524 1-218-941-81 METAL CHIP 100 5% 1/16W

R5525 1-218-941-81 METAL CHIP 100 5% 1/16W

R5526 1-218-941-81 METAL CHIP 100 5% 1/16W

R5527 1-218-941-81 METAL CHIP 100 5% 1/16W

R5551 1-218-941-81 METAL CHIP 100 5% 1/16W

R5552 1-218-941-81 METAL CHIP 100 5% 1/16W

R5555 1-218-939-11 METAL CHIP 68 5% 1/16W

R5556 1-218-935-11 METAL CHIP 33 5% 1/16W

R5557 1-218-941-81 METAL CHIP 100 5% 1/16W

R5558 1-218-941-81 METAL CHIP 100 5% 1/16W

R5564 1-218-939-11 METAL CHIP 68 5% 1/16W

R5565 1-218-941-81 METAL CHIP 100 5% 1/16W

R5566 1-218-941-81 METAL CHIP 100 5% 1/16W

R5567 1-218-941-81 METAL CHIP 100 5% 1/16W

R5568 1-218-941-81 METAL CHIP 100 5% 1/16W

R5569 1-218-935-11 METAL CHIP 33 5% 1/16W

R5581 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5582 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5583 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5584 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5585 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5586 1-218-990-81 SHORT CHIP 0

R5587 1-218-990-81 SHORT CHIP 0

R5588 1-218-941-11 METAL CHIP 100 5% 1/16W

R5589 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W

R5590 1-208-683-11 METAL CHIP 1K 0.5% 1/16W

R5591 1-218-965-11 METAL CHIP 10K 5% 1/16W

R5592 1-218-965-11 METAL CHIP 10K 5% 1/16W

R5593 1-218-965-11 METAL CHIP 10K 5% 1/16W

R5594 1-218-965-11 METAL CHIP 10K 5% 1/16W

R5596 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5597 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5598 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5599 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5600 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5601 1-218-977-11 METAL CHIP 100K 5% 1/16W

R5602 1-218-977-11 METAL CHIP 100K 5% 1/16W

< SWITCH >

S5501 1-786-723-11 SWITCH, TACTILE

S5502 1-786-723-11 SWITCH, TACTILE

< VARISTOR >

* VDR551 1-802-279-11 VARISTOR (SMD)

A-1752-128-A PD-395 BOARD, COMPLETE

**********************

< CAPACITOR >

C2001 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V

C2002 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V

C2003 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V

C2004 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C2005 1-165-875-11 CERAMIC CHIP 10uF 10% 10V

C2006 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V

* C2008 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V

C2009 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C2010 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V

C2011 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V

C2012 1-127-861-11 CERAMIC CHIP 2.2uF 10% 16V

C2013 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V

C2014 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V

C2015 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V

C2016 1-165-908-11 CERAMIC CHIP 1uF 10% 10V

C2017 1-165-908-11 CERAMIC CHIP 1uF 10% 10V

C2018 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V

C2019 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V

C2020 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V

C2021 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V

C2022 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V

C2023 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V

C2024 1-127-861-11 CERAMIC CHIP 2.2uF 10% 16V

< CONNECTOR >

* CN2001 1-821-760-21 CONNECTOR, COAXIAL (RECEPTACLE)

* CN2002 1-794-322-51 FFC/CONNECTOR, FPC (ZIF) 6P

* CN2003 1-794-322-51 FFC/CONNECTOR, FPC (ZIF) 6P

* CN2004 1-818-818-81 CONNECTOR, FPC (ZIF) 29P

* CN2005 1-817-942-81 CONNECTOR, FPC (ZIF) 39P

< DIODE >

D2002 8-719-069-29 DIODE RB520S-30FJTE61

D2003 8-719-069-29 DIODE RB520S-30FJTE61

< FERRITE BEAD >

FB2001 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)

< IC >

* IC2001 6-712-051-01 IC SN65LVDS302ZQER

< COIL >

* L2001 1-481-425-21 INDUCTOR 10uH

* L2002 1-481-425-21 INDUCTOR 10uH

* L2003 1-481-425-21 INDUCTOR 10uH

< TRANSISTOR >

Q2001 8-729-427-37 TRANSISTOR XP411F-TXE

Q2002 8-729-427-67 TRANSISTOR XP421F-TXE

< RESISTOR >

R2004 1-218-973-11 METAL CHIP 47K 5% 1/16W

R2006 1-218-940-11 METAL CHIP 82 5% 1/16W

R2007 1-218-973-11 METAL CHIP 47K 5% 1/16W

R2008 1-218-973-11 METAL CHIP 47K 5% 1/16W

R2009 1-218-973-11 METAL CHIP 47K 5% 1/16W

R2012 1-218-973-11 METAL CHIP 47K 5% 1/16W

R2014 1-218-973-11 METAL CHIP 47K 5% 1/16W

R2015 1-216-833-11 METAL CHIP 10K 5% 1/10W

R2018 1-216-833-11 METAL CHIP 10K 5% 1/10W

R2022 1-218-990-81 SHORT CHIP 0

A-1752-129-A PI-030 BOARD, COMPLETE

*********************

< CAPACITOR >

C2502 1-131-861-91 TANTAL. CHIP 4.7uF 20% 20V

C2504 1-165-908-11 CERAMIC CHIP 1uF 10% 10V

C2505 1-137-910-11 TANTAL. CHIP 10uF 20% 16V

C2506 1-165-908-11 CERAMIC CHIP 1uF 10% 10V

C2509 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V

C2511 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V

C2512 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V

C2513 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V

C2514 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V

C2515 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V

C2517 1-127-820-11 CERAMIC CHIP 4.7uF 10% 16V

< CONNECTOR >

* CN2501 1-821-760-21 CONNECTOR, COAXIAL (RECEPTACLE)

* CN2502 1-816-643-51 FFC/FPC CONNECTOR (LIF) 10P

CN2503 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P

CN2504 1-817-920-11 CONNECTOR, FPC (ZIF) 80P

CN2505 1-794-375-21 PIN, CONNECTOR 2P

* CN2507 1-816-650-51 FFC/CONNECTOR, FPC (LIF) 24P

CN2508 1-816-655-61 CONNECTOR, FFC/FPC 8P

* CN2509 1-817-697-51 CONNECTOR, FPC (ZIF) 19P

CN2510 1-691-346-61 CONNECTOR, FFC/FPC (ZIF) 8P

< IC >

IC2501 6-703-228-01 IC TK11160CSCL-G

IC2502 8-759-581-11 IC NJM2125F (TE2)

IC2503 8-759-581-11 IC NJM2125F (TE2)

IC2505 8-759-581-11 IC NJM2125F (TE2)

IC2508 8-759-564-49 IC TC7W53FU (TE12R)

IC2509 6-707-702-01 IC NJM2746RB1 (TE2)

IC2510 6-707-702-01 IC NJM2746RB1 (TE2)

< TRANSISTOR >

* Q2501 6-551-624-01 TRANSISTOR RN2102MFV (TL3SONY)

* Q2502 6-551-624-01 TRANSISTOR RN2102MFV (TL3SONY)

Q2503 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)

Q2504 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)

Q2505 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)

Q2507 8-729-044-37 TRANSISTOR LSK3019FP8TL

MA-459 MS-424 PD-395 PI-030
