Sony HXR-NX5C User Manual

HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
2-21
Ref. No. Part No. Description Ref. No. Part No. Description
Ref. No. Part No. Description
Ref. No. Part No. Description
C8518 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8519 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8520 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C8521 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C8522 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
< CONNECTOR >
CN8501 1-816-655-61 CONNECTOR, FFC/FPC 8P
< IC >
* IC8501 8-753-284-38 IC CXA3739AER-T2
< RESISTOR >
R8509 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R8510 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R8511 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R8512 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R8513 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R8514 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R8515 1-218-969-11 METAL CHIP 22K 5% 1/16W
R8516 1-218-969-11 METAL CHIP 22K 5% 1/16W
R8517 1-218-969-11 METAL CHIP 22K 5% 1/16W
R8518 1-218-969-11 METAL CHIP 22K 5% 1/16W
R8529 1-218-990-81 SHORT CHIP 0
R8530 1-218-990-81 SHORT CHIP 0
< SENSOR >
* SE8501 1-480-218-11 SENSOR, ANGULAR VELOCITY (31.2kHz) (PITCH)
* SE8502 1-479-022-61 SENSOR, ANGULAR VELOCITY (32.2kHz) (YAW)
A-1752-123-A HG-001 BOARD, COMPLETE
**********************
< CAPACITOR >
C7811 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C7813 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
* CN7801 1-817-544-71 CONNECTOR, FPC (ZIF) 39P
CN7802 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
* CN7803 1-817-829-81 CONNECTOR, FPC (ZIF) 27P
CN7804 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
< FILTER >
FL7801 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< RESISTOR >
R7801 1-218-970-11 METAL CHIP 27K 5% 1/16W
R7802 1-218-968-11 METAL CHIP 18K 5% 1/16W
R7821 1-218-990-81 SHORT CHIP 0
R7823 1-218-990-81 SHORT CHIP 0
R7824 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7825 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
< SWITCH >
S7801 1-771-487-11 SWITCH, SLIDE
A-1752-114-A HP-156 BOARD, COMPLETE
**********************
< CAPACITOR >
C3001 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3002 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3004 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C3005 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
< CONNECTOR >
CN3001 1-816-655-61 CONNECTOR, FFC/FPC 8P
< DIODE >
D3004 6-502-193-01 DIODE SML-D12V8WT86SN
< FERRITE BEAD >
* FB3001 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB3002 1-481-300-11 INDUCTOR, FERRITE BEAD
< JACK >
J3001 1-794-525-12 JACK, MIC
< COIL >
* L3001 1-481-381-21 INDUCTOR 100uH
* L3002 1-481-381-21 INDUCTOR 100uH
< TRANSISTOR >
Q3001 6-551-630-01 TRANSISTOR RN1102MFV (TL3SONY)
< RESISTOR >
R3002 1-218-990-81 SHORT CHIP 0
R3003 1-218-938-11 METAL CHIP 56 5% 1/16W
R3005 1-218-953-11 METAL CHIP 1K 5% 1/16W
A-1752-122-A HT-003 BOARD, COMPLETE
**********************
< CONNECTOR >
CN7401 1-794-375-21 PIN, CONNECTOR 2P
< SWITCH >
S7401 1-786-180-11 SWITCH, PUSH (1KEY)
A-1752-115-A JK-392 BOARD, COMPLETE
**********************
< CONNECTOR >
CN4001 1-819-780-61 CONNECTOR, FPC (ZIF) 27P
CN4002 1-794-962-11 CONNECTOR, SQUARE TYPE (USB 5P)
CN4003 1-818-607-12 CONNECTOR, SQUARE TYPE 10P
CN4004 1-816-655-61 CONNECTOR, FFC/FPC 8P
< RESISTOR >
R4010 1-218-965-11 METAL CHIP 10K 5% 1/16W
< VARISTOR >
* VDR401 1-802-279-11 VARISTOR (SMD)
* VDR402 1-802-279-11 VARISTOR (SMD)
* VDR403 1-802-279-11 VARISTOR (SMD)
A-1752-116-A KY-115 BOARD, COMPLETE
**********************
< CONNECTOR >
CN4501 1-816-655-61 CONNECTOR, FFC/FPC 8P
< RESISTOR >
R4502 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R4503 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R4504 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R4505 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R4506 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R4507 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R4508 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R4509 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R4510 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R4511 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
R4512 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
R4513 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
R4514 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R4515 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R4516 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R4517 1-218-970-11 METAL CHIP 27K 5% 1/16W
R4518 1-218-970-11 METAL CHIP 27K 5% 1/16W
< SWITCH >
S4501 1-786-157-31 TACTILE SWITCH
S4502 1-786-157-31 TACTILE SWITCH
S4503 1-786-157-31 TACTILE SWITCH
S4504 1-786-157-31 TACTILE SWITCH
S4505 1-786-157-31 TACTILE SWITCH
S4506 1-786-157-31 TACTILE SWITCH
S4507 1-786-157-31 TACTILE SWITCH
S4508 1-786-157-31 TACTILE SWITCH
S4509 1-786-157-31 TACTILE SWITCH
S4510 1-786-157-31 TACTILE SWITCH
S4511 1-786-157-31 TACTILE SWITCH
S4512 1-786-157-31 TACTILE SWITCH
S4513 1-786-157-31 TACTILE SWITCH
S4514 1-786-157-31 TACTILE SWITCH
S4515 1-786-157-31 TACTILE SWITCH
S4516 1-786-157-31 TACTILE SWITCH
S4517 1-786-157-31 TACTILE SWITCH
S4518 1-786-157-31 TACTILE SWITCH
S4519 1-786-157-31 TACTILE SWITCH
S4520 1-786-157-31 TACTILE SWITCH
S4521 1-786-157-31 TACTILE SWITCH
< VARISTOR >
* VDR001 1-802-279-11 VARISTOR (SMD)
* VDR002 1-802-279-11 VARISTOR (SMD)
* VDR003 1-802-279-11 VARISTOR (SMD)
* VDR004 1-802-279-11 VARISTOR (SMD)
A-1752-117-A MA-459 BOARD, COMPLETE
**********************
< CAPACITOR >
C5001 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C5002 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C5003 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C5004 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5005 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5006 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5007 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C5010 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5011 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5012 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5013 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C5016 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C5017 1-100-743-91 CERAMIC CHIP 2.2uF 20% 16V
< CONNECTOR >
CN5001 1-817-054-21 PIN, CONNECTOR 6P
* CN5002 1-817-697-51 CONNECTOR, FPC (ZIF) 19P
< DIODE >
D5001 6-502-193-01 DIODE SML-D12V8WT86SN
< IC >
IC5001 8-759-422-21 IC NJM4580V (TE2)
IC5002 8-759-422-21 IC NJM4580V (TE2)
< TRANSISTOR >
Q5001 6-551-630-01 TRANSISTOR RN1102MFV (TL3SONY)
< RESISTOR >
R5001 1-208-697-11 METAL CHIP 3.9K 0.5% 1/16W
R5002 1-208-697-11 METAL CHIP 3.9K 0.5% 1/16W
R5003 1-208-697-11 METAL CHIP 3.9K 0.5% 1/16W
R5004 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R5005 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R5006 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R5007 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R5008 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R5009 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R5010 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R5011 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R5012 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R5015 1-218-945-11 METAL CHIP 220 5% 1/16W
R5016 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5017 1-218-976-11 METAL CHIP 82K 5% 1/16W
R5018 1-218-941-81 METAL CHIP 100 5% 1/16W
R5019 1-218-941-81 METAL CHIP 100 5% 1/16W
HG-001 HP-156 HT-003 JK-392 KY-115 MA-459GY-022
