HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
2-20
Ref. No. Part No. Description Ref. No. Part No. Description
Ref. No. Part No. Description
Ref. No. Part No. Description
R1009 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
R1010 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
R1011 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
R1012 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R1013 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R1014 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R1015 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R1016 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R1017 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R1018 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R1019 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R1020 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R1021 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R1022 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R1023 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
< VARISTOR >
* VDR112 1-802-279-11 VARISTOR (SMD)
* VDR113 1-802-279-11 VARISTOR (SMD)
A-1752-099-A CP-004 BOARD, COMPLETE
**********************
< CAPACITOR >
C1503 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C1504 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
< CONNECTOR >
CN1501 1-816-655-61 CONNECTOR, FFC/FPC 8P
< FERRITE BEAD >
FB1501 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB1502 1-400-331-11 FERRITE, EMI (SMD) (1005)
< JACK >
J1501 1-780-836-11 TERMINAL BOARD
< RESISTOR >
R1501 1-218-990-81 SHORT CHIP 0
R1502 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1503 1-218-973-11 METAL CHIP 47K 5% 1/16W
< VARISTOR >
* VDR152 1-802-080-11 VARISTOR (SMD)
1-873-733-11 FP-776 FLEXIBLE BOARD
********************
A-1752-133-A FP-1149 FLEXIBLE BOARD, COMPLETE
*********************
< CONNECTOR >
* CN102 1-819-696-21 CONNECTOR, HDMI
A-1752-134-A FP-1150 FLEXIBLE BOARD, COMPLETE
*******************************
< CAPACITOR >
C2001 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2002 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2003 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< IC >
IC2001 6-600-163-01 IC RS-770
IC2002 6-600-513-11 IC TK60019CS8G0L
IC2003 6-600-513-11 IC TK60019CS8G0L
< RESISTOR >
R2001 1-216-805-11 METAL CHIP 47 5% 1/10W
A-1752-135-A FP-1151 FLEXIBLE BOARD, COMPLETE
*******************************
(CN301 is not supplied, but this is included in FP-1151 Flexible board.)
< CONNECTOR >
CN301 (Not supplied) CONNECTOR, MULTIPLE (SOCKET)
(CN301 is supplied included in FP-1151 complete flexible board.)
A-1752-136-A FP-1152 FLEXIBLE BOARD, COMPLETE
*******************************
< RESISTOR >
R401 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
< SWITCH >
S401 1-771-487-11 SWITCH, SLIDE
1-879-854-11 FP-1155 FLEXIBLE BOARD
*********************
1-879-855-11 FP-1156 FLEXIBLE BOARD
*********************
1-879-856-12 FP-1157 FLEXIBLE BOARD
*********************
1-879-857-11 FP-1158 FLEXIBLE BOARD
*********************
1-879-858-11 FP-1159 FLEXIBLE BOARD
*********************
1-879-859-11 FP-1160 FLEXIBLE BOARD
*********************
1-879-860-11 FP-1161 FLEXIBLE BOARD
*********************
1-879-883-11 FP-1162 FLEXIBLE BOARD
*********************
A-1752-113-A GC-012 BOARD, COMPLETE
**********************
(BT2001 is not included in GC-012 complete board.)
< BATTERY HOLDER >
BH2001 1-756-615-61 HOLDER, BATTERY (Note)
< BATTERY >
BT2001 1-756-134-12 BATTERY, STORAGE, LITHIUM (Note)
< CAPACITOR >
C2001 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C2002 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2003 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2004 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C2005 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C2008 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2009 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2010 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2012 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C2013 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2014 1-128-709-21 TANTAL. CHIP 68uF 20% 10V
C2015 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2016 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
C2017 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
< CONNECTOR >
* CN2001 1-779-333-51 CONNECTOR, FFC/FPC 18P
CN2002 1-779-328-51 CONNECTOR, FFC/FPC 8P
* CN2004 1-779-329-51 CONNECTOR, FFC/FPC 10P
* CN2005 1-779-327-51 CONNECTOR, FFC/FPC 6P
< DIODE >
D2001 8-719-074-67 DIODE EDZFJ-TE61-5.6B
D2002 8-719-083-91 DIODE EDZFJ-TE61-6.8B
< IC >
IC2001 8-759-058-62 IC TC7S08FU (TE85R)
IC2003 8-759-678-15 IC TLV2231CDBVR
IC2004 8-759-369-73 IC NJM4556AM
< RESISTOR >
R2006 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R2008 1-218-941-81 METAL CHIP 100 5% 1/16W
R2011 1-218-990-81 SHORT CHIP 0
R2012 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R2013 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2014 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2015 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R2016 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R2017 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R2018 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R2019 1-218-944-11 METAL CHIP 180 5% 1/16W
R2020 1-218-944-11 METAL CHIP 180 5% 1/16W
R2023 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R2024 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R2025 1-218-943-11 METAL CHIP 150 5% 1/16W
R2026 1-218-943-11 METAL CHIP 150 5% 1/16W
R2028 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R2029 1-218-949-11 METAL CHIP 470 5% 1/16W
< VARISTOR >
* VDR201 1-802-279-11 VARISTOR (SMD)
* VDR203 1-802-279-11 VARISTOR (SMD)
* VDR205 1-802-279-11 VARISTOR (SMD)
A-1752-124-A GS-010 BOARD, COMPLETE
(EXCEPT NX5C/NX5M)
**********************
< CONNECTOR >
CN8001 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
< SWITCH >
S8001 1-771-731-21 SWITCH, SLIDE
A-1759-066-A GY-022 BOARD, COMPLETE (SERVICE)
******************************
< CAPACITOR >
C8501 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C8502 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C8503 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C8504 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8505 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C8506 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C8507 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C8508 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C8509 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C8510 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C8511 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C8512 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8513 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C8514 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8515 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8516 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8517 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
FP-1160 FP-1161 FP-1162 GC-012 GS-010 GY-022FP-1152 FP-1155 FP-1156 FP-1157 FP-1158 FP-1159FP-1151CK-218 CP-004 FP-776 FP-1149 FP-1150
The changed portions from
Ver. 1.0 are shown in blue.
Ver. 1.1 2010.01
