HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
2-26
Ref. No. Part No. Description Ref. No. Part No. Description
Ref. No. Part No. Description Ref. No. Part No. Description
* D3001 6-502-947-01 DIODE RB751CS-40T2R
* D3002 6-502-947-01 DIODE RB751CS-40T2R
* D3003 6-502-947-01 DIODE RB751CS-40T2R
* D3004 6-502-947-01 DIODE RB751CS-40T2R
* D3005 6-502-947-01 DIODE RB751CS-40T2R
* D3006 6-502-947-01 DIODE RB751CS-40T2R
* D3007 6-502-947-01 DIODE RB751CS-40T2R
* D3008 6-502-947-01 DIODE RB751CS-40T2R
* D3009 6-502-947-01 DIODE RB751CS-40T2R
D3010 8-719-421-67 DIODE MA132WK
D3012 8-719-421-67 DIODE MA132WK
D4001 8-719-421-67 DIODE MA132WK
D4003 8-719-421-67 DIODE MA132WK
D4802 6-502-150-01 DIODE MA2SD320G8S0
D4803 6-502-150-01 DIODE MA2SD320G8S0
D5005 8-719-421-67 DIODE MA132WK
D5008 8-719-074-67 DIODE EDZFJ-TE61-5.6B
D5009 8-719-074-67 DIODE EDZFJ-TE61-5.6B
D5401 8-719-421-71 DIODE 1SS361-TE85L
D5402 8-719-421-71 DIODE 1SS361-TE85L
D8401 8-719-074-08 DIODE MA4ZD03001S0
< FUSE >
*F001 1-523-038-31 FUSE (0.25A/24V)
*F002 1-523-038-31 FUSE (0.25A/24V)
*F003 1-576-286-31 FUSE (1.4A/24V)
*F004 1-576-286-31 FUSE (1.4A/24V)
*F005 1-576-286-31 FUSE (1.4A/24V)
*F006 1-576-286-31 FUSE (1.4A/24V)
*F007 1-576-286-31 FUSE (1.4A/24V)
*F008 1-576-286-31 FUSE (1.4A/24V)
< FERRITE BEAD >
FB001 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
* FB1401 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB1402 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB1403 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB1404 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB1405 1-400-620-21 INDUCTOR, FERRITE BEAD (1005)
* FB1601 1-481-300-11 INDUCTOR, FERRITE BEAD
FB2301 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
* FB2302 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
* FB2303 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB2801 1-400-331-11 FERRITE, EMI (SMD) (1005)
* FB4401 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB4402 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB4403 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB4404 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB4405 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB4406 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB5602 1-481-300-11 INDUCTOR, FERRITE BEAD
< FILTER >
FL3401 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL3402 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC >
* IC1001 6-711-739-01 IC TC7WG126FK
IC1002 6-703-953-01 IC TK11134CSCL-G
IC1204 6-703-976-01 IC R1114Q181D-TR-FA
IC1205 6-703-976-01 IC R1114Q181D-TR-FA
IC1206 6-703-976-01 IC R1114Q181D-TR-FA
IC1207 6-703-976-01 IC R1114Q181D-TR-FA
IC1208 6-703-977-01 IC R1114Q331D-TR-FA
IC1209 6-703-977-01 IC R1114Q331D-TR-FA
* IC1401 6-710-308-01 IC CXD9891GG
* IC1403 6-708-444-01 IC R1114Q281D-TR-FA
IC1407 6-706-484-01 IC TC7SH04FU (T5RSOYJF)
IC1408 6-701-979-01 IC TC7WB66FK (TE85R)
IC1409 6-714-136-01 IC TC7SG125FU (T5RSY, F)
IC1410 6-714-136-01 IC TC7SG125FU (T5RSY, F)
* IC1601 6-713-564-01 IC IS42SM32160C-7BLI-TR U907A
IC2001 (Not supplied) IC BCX255102A
(IC2001 is supplied included in VC-582 complete board (service).)
IC2002 6-708-511-01 IC TC7SG08AFS
IC2302 6-712-850-01 IC TC7SP3125TU (5RSO, F
IC2601 (Not supplied) IC K5R1G13ACD-AK60T
(IC2601 is supplied included in VC-582 complete board (service).)
* IC2801 6-707-959-01 IC AN12920AAVB
IC2803 6-710-786-01 IC TC7SH125FU (T5RSOYF
IC2804 6-710-786-01 IC TC7SH125FU (T5RSOYF
* IC2806 6-712-910-01 IC NJM2878F4-46 (TE2)
* IC2807 6-714-540-01 IC MAX9654AUB+T
* IC2808 6-714-525-01 IC BH7606GU
* IC2809 6-712-135-01 IC R1173H001D-T1-F
* IC3001 6-714-362-01 IC EP3C16U256C8N
IC3002 6-700-217-01 IC TC7SZ14FU (TE85R)
IC3003 6-707-886-01 IC TC74VHCT125AFT (EKJ)
IC3004 6-710-786-01 IC TC7SH125FU (T5RSOYF
IC3005 6-710-786-01 IC TC7SH125FU (T5RSOYF
* IC3006 6-714-750-01 IC HD74LV1GT125AVSE
* IC3007 6-808-742-01 IC EPCS4SI8N (15)-BZ01
* IC3201 6-714-015-01 IC K4X56323PL-8GC6T
* IC3301 6-708-464-01 IC R1114Q251D-TR-FA
IC3302 6-705-606-01 IC R1114Q301D-TR-FA
IC3303 6-703-977-01 IC R1114Q331D-TR-FA
IC3304 6-703-977-01 IC R1114Q331D-TR-FA
IC3306 6-703-976-01 IC R1114Q181D-TR-FA
* IC3401 8-753-335-26 IC CXD4113GG-T6
* IC3601 6-714-780-01 IC K4X51323PG-8GC6T
* IC3701 6-712-050-01 IC SN65LVDS301ZQER
* IC4001 6-714-362-01 IC EP3C16U256C8N
* IC4002 6-808-743-01 IC EPCS4SI8N (15)-ST01
IC4003 6-714-136-01 IC TC7SG125FU (T5RSY, F)
IC4005 6-710-786-01 IC TC7SH125FU (T5RSOYF
IC4007 6-710-786-01 IC TC7SH125FU (T5RSOYF
IC4008 8-759-524-04 IC TC74VHC125FT (EL)
IC4009 6-710-786-01 IC TC7SH125FU (T5RSOYF
* IC4403 6-712-135-01 IC R1173H001D-T1-F
* IC4404 6-712-135-01 IC R1173H001D-T1-F
* IC4405 6-712-905-01 IC GS1572-IBE3
IC4601 6-703-976-01 IC R1114Q181D-TR-FA
* IC4602 6-708-464-01 IC R1114Q251D-TR-FA
* IC4801 6-713-468-01 IC ADV7521NKBCBZRL-80
IC4802 6-705-337-01 IC TK11150CSCL-G
* IC5201 6-808-414-01 IC MB44C017ABGF-G-ERE1
* IC5401 6-714-858-01 IC MB95005ABGL-G-125-ERE1
* IC5601 6-714-950-01 IC MB91195ABGL-G-270-ERE1
* IC5602 6-706-013-01 IC AK6514CF-E2
IC5603 6-704-974-01 IC AK6512CAS-E2
* IC6002 6-808-503-01 IC BU24130GU-E2
* IC6201 6-808-503-01 IC BU24130GU-E2
* IC6401 6-713-274-01 IC R2J30502LG
* IC6601 6-712-910-01 IC NJM2878F4-46 (TE2)
* IC6602 6-708-444-01 IC R1114Q281D-TR-FA
IC8001 6-707-104-01 IC NJM2761RB2 (TE2)
IC8002 6-702-527-01 IC AK5380VT-E2
* IC8003 6-713-574-01 IC R2A15219FP
IC8004 6-704-682-01 IC AK4384VT-E2
* IC8005 6-708-446-01 IC R1114Q311D-TR-FA
IC8006 6-707-616-01 IC AK4386VT-E2
IC8007 6-707-879-01 IC TC74VHC541FT (EKJ)
IC8008 6-707-208-01 IC TK11100CSCB-G
* IC8403 6-712-910-01 IC NJM2878F4-46 (TE2)
IC8405 6-709-933-01 IC XC9103D093MR
< COIL >
* L1401 1-481-425-21 INDUCTOR 10uH
* L1402 1-481-425-21 INDUCTOR 10uH
* L1403 1-481-425-21 INDUCTOR 10uH
L1408 1-400-353-21 INDUCTOR 22uH
* L2001 1-481-425-21 INDUCTOR 10uH
* L2003 1-481-425-21 INDUCTOR 10uH
* L2004 1-481-425-21 INDUCTOR 10uH
* L2005 1-481-425-21 INDUCTOR 10uH
* L2006 1-481-425-21 INDUCTOR 10uH
* L2007 1-481-425-21 INDUCTOR 10uH
* L2008 1-481-425-21 INDUCTOR 10uH
* L2009 1-481-425-21 INDUCTOR 10uH
* L2803 1-481-425-21 INDUCTOR 10uH
* L2808 1-481-425-21 INDUCTOR 10uH
L3001 1-469-553-21 INDUCTOR 4.7uH
* L3002 1-400-672-11 INDUCTOR 1uH
* L3003 1-400-672-11 INDUCTOR 1uH
* L3004 1-481-102-21 INDUCTOR 10uH
* L3701 1-481-425-21 INDUCTOR 10uH
L4401 1-414-836-21 INDUCTOR 4.7nH
L4402 1-414-836-21 INDUCTOR 4.7nH
L4601 1-469-553-21 INDUCTOR 4.7uH
* L4602 1-400-672-11 INDUCTOR 1uH
* L4603 1-481-102-21 INDUCTOR 10uH
* L4802 1-481-425-21 INDUCTOR 10uH
* L4804 1-481-425-21 INDUCTOR 10uH
L5202 1-456-135-11 INDUCTOR 4.7uH
L5203 1-419-630-21 INDUCTOR 4.7uH
L5204 1-456-135-11 INDUCTOR 4.7uH
L5205 1-456-135-11 INDUCTOR 4.7uH
L5206 1-456-135-11 INDUCTOR 4.7uH
L5207 1-456-135-11 INDUCTOR 4.7uH
L5208 1-456-135-11 INDUCTOR 4.7uH
L5210 1-469-553-21 INDUCTOR 4.7uH
* L5211 1-400-411-21 INDUCTOR 4.7uH
L5212 1-469-553-21 INDUCTOR 4.7uH
* L5213 1-481-425-21 INDUCTOR 10uH
L5214 1-469-553-21 INDUCTOR 4.7uH
* L5216 1-457-647-11 INDUCTOR 100uH
L6002 1-469-967-21 INDUCTOR 10uH
L6202 1-469-967-21 INDUCTOR 10uH
L6401 1-469-967-21 INDUCTOR 10uH
* L6601 1-481-425-21 INDUCTOR 10uH
* L8001 1-481-425-21 INDUCTOR 10uH
* L8002 1-481-425-21 INDUCTOR 10uH
L8003 1-400-353-21 INDUCTOR 22uH
* L8004 1-481-425-21 INDUCTOR 10uH
* L8005 1-481-425-21 INDUCTOR 10uH
L8006 1-469-967-21 INDUCTOR 10uH
* L8007 1-481-425-21 INDUCTOR 10uH
L8008 1-456-138-11 INDUCTOR 33uH
L8009 1-456-138-11 INDUCTOR 33uH
* L8010 1-481-425-21 INDUCTOR 10uH
L8401 1-416-670-51 INDUCTOR 33uH
L8402 1-456-499-11 INDUCTOR 4.7uH
< FILTER >
LF4801 1-457-223-11 COMMON MODE CHOKE COIL
LF4802 1-457-223-11 COMMON MODE CHOKE COIL
LF4803 1-457-223-11 COMMON MODE CHOKE COIL
LF4804 1-457-223-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
Q1001 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)
* Q2001 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q2002 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q2003 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q2004 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q2005 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q2006 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q2007 6-551-771-01 TRANSISTOR UNR31AFG0LS0
Q2008 6-551-622-01 TRANSISTOR 2SC6026MFV (TL3SONY)
* Q4001 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
Q4802 6-550-179-01 TRANSISTOR RN4904FE (TPLR3)
* Q5003 6-552-123-01 TRANSISTOR ECH8652-S-TL-H
Q5004 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)
Q5005 6-551-184-01 TRANSISTOR MCH6305-TL-E-S
Q5201 8-729-055-88 TRANSISTOR MCH3406-TL-E
* Q5202 6-552-054-01 TRANSISTOR SCH2825-TL-E
Q6401 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)
Q6402 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)
* Q6403 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q6404 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q6601 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q6602 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q6603 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
* Q6604 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3SONY)
Q6605 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)
Q8001 8-729-202-38 TRANSISTOR 2SC3326N-A
Q8002 8-729-202-38 TRANSISTOR 2SC3326N-A
Q8003 8-729-202-38 TRANSISTOR 2SC3326N-A
Q8004 8-729-202-38 TRANSISTOR 2SC3326N-A
Q8005 8-729-202-38 TRANSISTOR 2SC3326N-A
Q8006 8-729-202-38 TRANSISTOR 2SC3326N-A
Q8403 6-551-622-01 TRANSISTOR 2SC6026MFV (TL3SONY)
Q8404 6-551-184-01 TRANSISTOR MCH6305-TL-E-S
* Q8405 6-552-311-01 TRANSISTOR MCH5837-TL-E
VC-582
