HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
2-27
Ref. No. Part No. Description Ref. No. Part No. Description
Ref. No. Part No. Description Ref. No. Part No. Description
< RESISTOR >
R1021 1-218-949-11 METAL CHIP 470 5% 1/16W
R1022 1-218-949-11 METAL CHIP 470 5% 1/16W
R1023 1-216-864-11 SHORT CHIP 0
R1054 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1055 1-218-949-11 METAL CHIP 470 5% 1/16W
R1201 1-218-990-81 SHORT CHIP 0
R1220 1-218-990-81 SHORT CHIP 0
R1221 1-218-990-81 SHORT CHIP 0
R1222 1-218-990-81 SHORT CHIP 0
R1223 1-218-990-81 SHORT CHIP 0
R1224 1-218-990-81 SHORT CHIP 0
R1225 1-218-990-81 SHORT CHIP 0
R1228 1-218-990-81 SHORT CHIP 0
R1229 1-218-990-81 SHORT CHIP 0
R1235 1-216-864-11 SHORT CHIP 0
R1401 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1402 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1403 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1404 1-218-990-81 SHORT CHIP 0
R1407 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1408 1-218-990-81 SHORT CHIP 0
R1411 1-218-990-81 SHORT CHIP 0
R1417 1-216-864-11 SHORT CHIP 0
R1431 1-218-990-81 SHORT CHIP 0
R1432 1-218-990-81 SHORT CHIP 0
R1433 1-218-990-81 SHORT CHIP 0
R1441 1-218-990-81 SHORT CHIP 0
R1444 1-218-990-81 SHORT CHIP 0
R1451 1-218-935-11 METAL CHIP 33 5% 1/16W
R1452 1-218-935-11 METAL CHIP 33 5% 1/16W
R1453 1-218-935-11 METAL CHIP 33 5% 1/16W
R1605 1-218-990-81 SHORT CHIP 0
R2001 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2002 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2003 1-218-990-81 SHORT CHIP 0
R2004 1-218-933-11 METAL CHIP 22 5% 1/16W
R2006 1-218-941-81 METAL CHIP 100 5% 1/16W
R2007 1-218-951-11 METAL CHIP 680 5% 1/16W
R2008 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R2009 1-218-951-11 METAL CHIP 680 5% 1/16W
R2010 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R2011 1-218-951-11 METAL CHIP 680 5% 1/16W
R2012 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R2013 1-218-941-11 METAL CHIP 100 5% 1/16W
* R2014 1-208-869-11 METAL CHIP 180 0.5% 1/16W
* R2015 1-208-869-11 METAL CHIP 180 0.5% 1/16W
R2016 1-208-671-11 METAL CHIP 330 0.5% 1/16W
R2017 1-208-671-11 METAL CHIP 330 0.5% 1/16W
R2018 1-208-671-11 METAL CHIP 330 0.5% 1/16W
R2019 1-218-990-81 SHORT CHIP 0
R2020 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2021 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R2022 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R2023 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R2025 1-218-935-11 METAL CHIP 33 5% 1/16W
R2026 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R2027 1-218-935-11 METAL CHIP 33 5% 1/16W
R2028 1-216-864-11 SHORT CHIP 0
R2030 1-218-935-11 METAL CHIP 33 5% 1/16W
R2031 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R2033 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2034 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R2035 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R2038 1-218-990-81 SHORT CHIP 0
R2044 1-218-990-81 SHORT CHIP 0
R2045 1-218-990-81 SHORT CHIP 0
R2049 1-218-985-11 METAL CHIP 470K 5% 1/16W
R2050 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2201 1-216-864-11 SHORT CHIP 0
R2202 1-216-864-11 SHORT CHIP 0
R2203 1-216-864-11 SHORT CHIP 0
R2204 1-218-990-81 SHORT CHIP 0
R2205 1-218-990-81 SHORT CHIP 0
R2305 1-218-929-11 METAL CHIP 10 5% 1/16W
R2306 1-218-935-11 METAL CHIP 33 5% 1/16W
R2307 1-218-935-11 METAL CHIP 33 5% 1/16W
R2311 1-218-933-11 METAL CHIP 22 5% 1/16W
R2312 1-218-933-11 METAL CHIP 22 5% 1/16W
R2313 1-218-933-11 METAL CHIP 22 5% 1/16W
R2315 1-218-935-11 METAL CHIP 33 5% 1/16W
R2316 1-218-935-11 METAL CHIP 33 5% 1/16W
R2317 1-218-935-11 METAL CHIP 33 5% 1/16W
R2319 1-218-990-81 SHORT CHIP 0
R2324 1-218-990-81 SHORT CHIP 0
R2325 1-218-941-81 METAL CHIP 100 5% 1/16W
R2326 1-218-941-81 METAL CHIP 100 5% 1/16W
R2327 1-218-941-81 METAL CHIP 100 5% 1/16W
R2328 1-218-941-81 METAL CHIP 100 5% 1/16W
R2329 1-218-941-81 METAL CHIP 100 5% 1/16W
R2334 1-218-940-11 METAL CHIP 82 5% 1/16W
R2335 1-218-990-81 SHORT CHIP 0
R2336 1-218-990-81 SHORT CHIP 0
R2337 1-218-935-11 METAL CHIP 33 5% 1/16W
R2342 1-218-940-11 METAL CHIP 82 5% 1/16W
R2343 1-218-941-81 METAL CHIP 100 5% 1/16W
R2348 1-218-941-81 METAL CHIP 100 5% 1/16W
R2349 1-218-941-81 METAL CHIP 100 5% 1/16W
R2350 1-218-941-81 METAL CHIP 100 5% 1/16W
R2351 1-218-941-81 METAL CHIP 100 5% 1/16W
R2352 1-218-935-11 METAL CHIP 33 5% 1/16W
R2356 1-218-990-81 SHORT CHIP 0
R2357 1-218-990-81 SHORT CHIP 0
R2358 1-218-941-81 METAL CHIP 100 5% 1/16W
R2359 1-218-941-81 METAL CHIP 100 5% 1/16W
R2360 1-218-941-81 METAL CHIP 100 5% 1/16W
R2361 1-218-941-81 METAL CHIP 100 5% 1/16W
R2362 1-218-941-81 METAL CHIP 100 5% 1/16W
R2363 1-218-940-11 METAL CHIP 82 5% 1/16W
R2521 1-218-990-81 SHORT CHIP 0
R2571 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2572 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2573 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2574 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2601 1-218-935-11 METAL CHIP 33 5% 1/16W
R2602 1-218-945-11 METAL CHIP 220 5% 1/16W
R2603 1-218-990-81 SHORT CHIP 0
R2609 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2803 1-218-990-81 SHORT CHIP 0
R2804 1-218-990-81 SHORT CHIP 0
R2808 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R2823 1-218-948-11 METAL CHIP 390 5% 1/16W
R2824 1-218-948-11 METAL CHIP 390 5% 1/16W
R2825 1-218-948-11 METAL CHIP 390 5% 1/16W
R2826 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R2827 1-208-675-11 METAL CHIP 470 0.5% 1/16W
R2828 1-208-675-11 METAL CHIP 470 0.5% 1/16W
R2829 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R2830 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R2831 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R2834 1-218-941-11 METAL CHIP 100 5% 1/16W
R2835 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R2836 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R2838 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2839 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3002 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3005 1-218-929-11 METAL CHIP 10 5% 1/16W
R3011 1-218-935-11 METAL CHIP 33 5% 1/16W
R3012 1-218-990-81 SHORT CHIP 0
R3019 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R3020 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R3022 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R3023 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R3024 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R3029 1-218-929-11 METAL CHIP 10 5% 1/16W
R3030 1-218-929-11 METAL CHIP 10 5% 1/16W
R3031 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3032 1-218-941-81 METAL CHIP 100 5% 1/16W
R3033 1-218-933-11 METAL CHIP 22 5% 1/16W
R3035 1-218-935-11 METAL CHIP 33 5% 1/16W
R3039 1-218-985-11 METAL CHIP 470K 5% 1/16W
R3040 1-218-935-11 METAL CHIP 33 5% 1/16W
R3041 1-218-935-11 METAL CHIP 33 5% 1/16W
R3042 1-218-935-11 METAL CHIP 33 5% 1/16W
R3043 1-218-935-11 METAL CHIP 33 5% 1/16W
R3044 1-218-935-11 METAL CHIP 33 5% 1/16W
R3045 1-218-935-11 METAL CHIP 33 5% 1/16W
R3046 1-218-935-11 METAL CHIP 33 5% 1/16W
R3047 1-218-935-11 METAL CHIP 33 5% 1/16W
R3048 1-218-935-11 METAL CHIP 33 5% 1/16W
R3301 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R3407 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3408 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3409 1-218-941-81 METAL CHIP 100 5% 1/16W
R3410 1-218-941-81 METAL CHIP 100 5% 1/16W
R3411 1-218-933-11 METAL CHIP 22 5% 1/16W
R3601 1-218-990-81 SHORT CHIP 0
R3709 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3710 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3711 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3714 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3715 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3716 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3717 1-218-990-81 SHORT CHIP 0
R3718 1-218-990-81 SHORT CHIP 0
R3719 1-218-990-81 SHORT CHIP 0
R3720 1-218-990-81 SHORT CHIP 0
R3721 1-218-990-81 SHORT CHIP 0
R3722 1-218-990-81 SHORT CHIP 0
R3723 1-218-990-81 SHORT CHIP 0
R3724 1-218-990-81 SHORT CHIP 0
R4003 1-218-933-11 METAL CHIP 22 5% 1/16W
R4004 1-218-935-11 METAL CHIP 33 5% 1/16W
R4005 1-218-935-11 METAL CHIP 33 5% 1/16W
R4008 1-218-941-81 METAL CHIP 100 5% 1/16W
R4009 1-218-941-81 METAL CHIP 100 5% 1/16W
R4010 1-218-941-81 METAL CHIP 100 5% 1/16W
R4011 1-218-941-81 METAL CHIP 100 5% 1/16W
R4018 1-218-935-11 METAL CHIP 33 5% 1/16W
R4019 1-218-935-11 METAL CHIP 33 5% 1/16W
R4071 1-218-935-11 METAL CHIP 33 5% 1/16W
R4085 1-218-990-81 SHORT CHIP 0
R4111 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4113 1-218-941-81 METAL CHIP 100 5% 1/16W
R4115 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4117 1-218-969-11 METAL CHIP 22K 5% 1/16W
R4122 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4123 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4124 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4125 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4126 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4129 1-218-941-81 METAL CHIP 100 5% 1/16W
R4142 1-218-977-11 METAL CHIP 100K 5% 1/16W
R4143 1-218-941-11 METAL CHIP 100 5% 1/16W
R4149 1-218-935-11 METAL CHIP 33 5% 1/16W
R4150 1-218-935-11 METAL CHIP 33 5% 1/16W
R4152 1-218-935-11 METAL CHIP 33 5% 1/16W
R4154 1-218-990-81 SHORT CHIP 0
R4155 1-218-968-11 METAL CHIP 18K 5% 1/16W
R4156 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4414 1-218-935-11 METAL CHIP 33 5% 1/16W
R4443 1-218-941-11 METAL CHIP 100 5% 1/16W
R4444 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R4445 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R4446 1-208-661-11 METAL CHIP 120 0.5% 1/16W
R4447 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R4448 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R4449 1-218-990-81 SHORT CHIP 0
R4450 1-218-990-81 SHORT CHIP 0
R4451 1-218-990-81 SHORT CHIP 0
R4452 1-218-990-81 SHORT CHIP 0
R4453 1-218-990-81 SHORT CHIP 0
R4454 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R4455 1-218-990-81 SHORT CHIP 0
R4456 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4457 1-240-582-11 METAL CHIP 6.8 5% 1/16W
R4458 1-218-990-81 SHORT CHIP 0
R4459 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R4460 1-218-990-81 SHORT CHIP 0
R4461 1-218-990-81 SHORT CHIP 0
R4462 1-218-990-81 SHORT CHIP 0
R4463 1-208-884-81 METAL CHIP 750 0.5% 1/16W
R4464 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R4465 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R4466 1-208-661-11 METAL CHIP 120 0.5% 1/16W
VC-582
