Help Guide
Interchangeable Lens Digital Camera
ILCE-1 α1
Bottom
Lock lever1.
Battery insertion slot2.
Battery cover
When attaching an accessory such as a vertical grip (sold separately), remove the battery cover.
To remove the battery cover
Pull the battery cover release lever (A) in the direction of the arrow, and then remove the battery cover.
To attach the battery cover
Insert the shaft on one side of the battery cover into the attachment site, and then push in the battery cover by
attaching the shaft on the opposite side.
3.
