Identifying parts
See the pages in parentheses for details on operation for the parts.
When the lens is removed
A Power switch/Shutter button
B Front dial
C Remote sensor
D Wi-Fi antenna (built-in)
E Lens release button
F Built-in microphone*
1
G AF illuminator (37)/Self-timer
lamp
H Mount index
I Image sensor*
2
J Mount
K Contacts*
2
*1 Do not cover this part during movie
recording.
Doing so may cause noise or lower
the volume.
*2 Do not directly touch these parts.
Front side
