Help Guide
Interchangeable Lens Digital Camera
ILME-FX3 Ver.2 or later
Front side
1 button (Custom button 1)/IRIS (Iris) button1.
Shutter button2.
W/T (zoom) lever3.
Front dial
You can quickly adjust the settings for each shooting mode.
4.
Infrared remote sensor5.
WLAN antenna (built-in)
Wi-Fi communication may be blocked if you cover this part with your hand, etc.
6.
Lens release button7.
AF illuminator/Self-timer lamp/Visible light and IR sensor
Do not cover this part during shooting.
8.
Recording lamp9.
6 button (Custom button 6)/REC (Recording) button10.
Mounting index11.
Image sensor*12.
Mount13.
Lens contacts*14.
Do not directly touch these parts.
*
