Help Guide
Interchangeable Lens Digital Camera
ILX-LR1
USB Streaming (movie)
You can connect a computer, etc. to the camera and use the camera video for livestreaming or web-conferencing
services. Select MENU → (Setup) → [USB] → [USB Connection Mode] → [Sel. When Connect] or [USB Streaming]
beforehand.
Menu item details
Output Res/Frame Rate:
Sets the resolution and the frame rate of the video. ([4K(2160p) 30p]/[4K(2160p) 25p]/[4K(2160p)
15p]/[4K(2160p)12.5p]/[HD(1080p) 60p]/[HD(1080p) 50p]/[HD(1080p) 30p]/[HD(1080p) 25p]/[HD(720p) 30p]/[HD(720p)
25p])
Movie Rec During Streaming:
Sets whether or not to enable recording of the video to the recording media during streaming. ([Enable]/[Disable])
Hint
The format of the streaming data is as follows.
Video format: MJPEG
*
or YUV420
This camera does not support audio output.
Note
While USB streaming is in progress, the camera is always set to the movie recording mode regardless of the position of the
Still/Movie/S&Q switch.
You cannot do the following while USB Streaming is running.
Transition to the playback screen
Network functions (PC remote, FTP transfer, remote operation from a smartphone, Bluetooth function, etc.)
MENU → (Network) → [Streaming] → [ USB Streaming] → Set [Output Res/Frame Rate] and [Movie
Rec During Streaming].
1
Connect the camera to a computer or other device with a commercially available USB cable.
[Streaming:Standby] will appear on the monitor, and the camera will switch to the streaming standby state.
If [USB Connection Mode] is set to [Sel. When Connect], select [Live Stream(USB Streaming)] on the selection
screen for the USB connection mode.
Use a cable or adapter that matches the terminal on the device to be connected.
2
Start streaming from your livestreaming/web-conferencing service.
[Streaming:Output] will appear on the monitor.
To exit USB Streaming, turn off the power of the camera or disconnect the USB cable.
3
When the resolution is set to HD (720p), only MJPEG is available.
*
