Administrating the Camera
Setting the Camera Image and Audio — Camera Menu
41
• JPEG - 1280 × 960 (Quad-VGA) : MPEG4 - 320 ×
240 (QVGA)
• JPEG - 960 × 720 : MPEG4 - OFF
• JPEG - 768 × 576 : MPEG4 - OFF
• JPEG - 640 × 480 (VGA): MPEG4 - 640 × 480
(VGA)
• JPEG - 384 × 288 : MPEG4 - 384 × 288
• JPEG - 320 × 240 (QVGA) : MPEG4 - 320 × 240
(QVGA)
Notes
• JPEG image cropping becomes active only when
JPEG output size is 1280 × 960 (Quad-VGA) and
MPEG4 is OFF.
• Superimpose works only when JPEG image cropping
is Off. When the image size is JPEG - 1280 × 960
(Quad-VGA) : MPEG4 - OFF : JPEG image
cropping available (page 40), you cannot set the
superimpose.
• Light funnel does not work when the followings are
set:
– Image size is JPEG - 960 × 720 : MPEG4 - OFF or
JPEG - 768 × 576 : MPEG4 - OFF.
– JPEG image cropping is On (With JPEG - 1280 ×
960 (Quad-VGA) : MPEG4 - OFF : JPEG
cropping available)
– SolidPTZ is On.
– Iris open is On.
• When the JPEG output image size is set to 1280 × 960
(Quad-VGA), the output image changes to 640 × 480
(VGA) regardless of the setting during Light funnel
on.
• When Light funnel is off, the maximum frame rate is
15 (fps). If you set a value more than 15 (fps), the
image is output by 15 (fps).
•When Video output mode (page 33) is set to NTSC +
IP or PAL + IP, or Iris open is On (page 33),
cropping, superimpose, privacy masking and
SolidPTZ are disabled regardless of the settings.
