REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
- 104 -
H1AG H2
< IC >
IC1000 6-703-744-01 IC GP1UE26SXKOF
< TRANSISTOR >
Q1010 8-729-010-29 TRANSISTOR MSD601-RST1
Q1011 8-729-010-29 TRANSISTOR MSD601-RST1
Q1012 8-729-010-29 TRANSISTOR MSD601-RST1
Q1013 8-729-010-29 TRANSISTOR MSD601-RST1
< RESISTOR >
R6310 1-216-864-11 SHORT CHIP 0
R6311 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6312 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6313 1-216-817-11 METAL CHIP 470 5% 1/10W
R6314 1-216-813-11 METAL CHIP 220 5% 1/10W
R6315 1-216-817-11 METAL CHIP 470 5% 1/10W
R6316 1-216-817-11 METAL CHIP 470 5% 1/10W
R6317 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6318 1-216-813-11 METAL CHIP 220 5% 1/10W
R6319 1-216-813-11 METAL CHIP 220 5% 1/10W
R6320 1-216-017-91 RES-CHIP 47 5% 1/10W
R6321 1-216-817-11 METAL CHIP 470 5% 1/10W
R6322 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6323 1-218-837-11 METAL CHIP 390 0.5% 1/10W
< SWITCH >
S1000 1-692-431-21 SWITCH, TACTILE
* A-1107-970-A H1 BOARD COMPLETE
< CONNECTOR >
CN4404 * 1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
D4401 8-719-069-55 DIODE UDZSTE-175.6B
D4402 8-719-069-55 DIODE UDZSTE-175.6B
< RESISTOR >
R4420 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R4421 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R4422 1-216-864-11 SHORT CHIP 0
R4423 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W
R4424 1-218-837-11 METAL CHIP 390 0.5% 1/10W
R4425 1-218-827-11 METAL CHIP 150 0.5% 1/10W
< SWITCH >
S4400 1-692-431-21 SWITCH, TACTILE
S4402 1-692-431-21 SWITCH, TACTILE
R6256 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6262 1-216-834-11 METAL CHIP 12K 5% 1/10W
R6263 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6264 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6267 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6303 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6308 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6309 1-216-821-11 METAL CHIP 1K 5% 1/10W
< RELAY >
RY1601 £ 1-755-395-11 RELAY (AC POWER)
< FILTER >
SF1001 1-795-617-11 SAW FILTER
SF1003 1-767-083-11 FILTER, SURFACE WAVE
< TRANSFORMER >
T1200 1-417-646-11 RF SPLITTER
T1603 £ 1-435-512-21 TRANSFORMER, CONVERTER (PIT)
T1605 £ 1-433-488-31 TRANSFORMER, LINE FILTER
T6300 £ 1-443-114-11 TRANSFORMER, STANDBY
< TUNER >
TU1001 8-597-953-00 TUNER, FSS BTP-AC431
TU1230 8-597-998-00 TUNER, FSS BTP-DC411
< VARISTOR >
VD1602 £ 1-804-995-11 VARISTOR
< CRYSTAL >
X1001 1-767-704-11 VIBRATOR, CRYSTAL
X4200 1-760-105-11 VIBRATOR, CRYSTAL
* A-1107-971-A H2 BOARD COMPLETE
< CAPACITOR >
C2000 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C9001 1-119-667-11 CERAMIC CHIP 22UF 10V
C9002 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
< CONNECTOR >
CN1000 * 1-564-526-31 PLUG, CONNECTOR 11P
< DIODE >
D1700 8-719-069-55 DIODE UDZSTE-175.6B
D1701 8-719-069-55 DIODE UDZSTE-175.6B
D1702 8-719-064-11 DIODE SPR-325MVW
D1704 8-719-064-11 DIODE SPR-325MVW
D1705 8-719-053-43 DIODE SLR-325VCT31
