Sony KDF-E42A11E - White Balance Adjustment (C;O); SECAM White Balance Adjustment (H;L)

- 28 -
KF-E42/50A11E
RM-ED002
ENOTROLOCLARTUEN
TESFFO_CIP_U042
TESFFO_TRB_U252
TESFFO_ROLOC_U821
HME_ROLOC0
TSARTNOCXAM
SSENTHGIRB05
ROLOC0
EUH0
SSENPRAHS0
THGILKCABXAM
RNOTUAFFO
ELBATTS_KCALB0
ROSNESTHGILFFO
GNIVASREWOPDRADNATS
4-2-3.SECAM White Balance adjustment (H/L)
1. Select AV0.
2. Change the TV to Custom Mode and set the following registers by
sending “TT54”.
3. Input SECAM CVBS 60 IRE Full Field Signal to AV1.
4. Adjust Drive registers:
SECAM_OFFSET_RD (R Drive)
SECAM_OFFSET_BD (B Drive)
High light adjustment value (9300K-0MPCD)
ENOTROLOCLARTUEN
TESFFO_CIP_U042
TESFFO_TRB_U252
TESFFO_ROLOC_U821
HME_ROLOC0
TSARTNOCXAM
SSENTHGIRB05
ROLOC0
EUH0
SSENPRAHS0
THGILKCABXAM
RNOTUAFFO
ELBATTS_KCALB0
ROSNESTHGILFFO
GNIVASREWOPDRADNATS
4-2-2.White Balance adjustment (C/O)
1. Select AV0.
2. Change the TV to Custom Mode and set the following registers by
sending “TT54”.
3. Input PAL CVBS 20 IRE Full Field Signal to AV1.
4. Adjust CutOff registers:
NORMAL_PAL_RC (R cutoff)
NORMAL_PAL_BC (B cutoff)
Low light ( Cut Off) adjustment value (9300K-0MPCD)
