– 22 –
KDF-E42/50A11E
RM-ED002
SECTION 3 DISASSEMBLY
3-2. PILLAR REMOVAL3-1. REAR COVER REMOVAL
3-4. MAIN BRACKET REMOVAL3-3. MAIN BRACKET COVER REMOVAL
