REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
- 86 -
IC5740 8-759-533-85 IC L88M05T-FA-TL
IC6309 8-759-576-76 IC TDA2822D013TR
IC7402 8-752-072-94 IC CXA1875AM-T4
IC7403 6-706-137-01 IC K6F2008V2E-LF70T00
IC7804 6-701-031-11 IC MSP3411G-QA-B11
IC8500 8-752-072-94 IC CXA1875AM-T4
IC9500 8-752-089-33 IC CXA2069Q-TL
< SOCKET >
J2802 1-819-255-11 PIN JACK 2P
J9154 1-819-721-11 PIN JACK 5P
< COIL >
L1000 1-412-058-11 INDUCTOR 10UH
L2500 1-412-029-11 INDUCTOR 10UH
L2502 1-412-029-11 INDUCTOR 10UH
L2504 1-412-029-11 INDUCTOR 10UH
L2506 1-412-029-11 INDUCTOR 10UH
L2507 1-412-029-11 INDUCTOR 10UH
L2508 1-412-029-11 INDUCTOR 10UH
L2509 1-412-029-11 INDUCTOR 10UH
L2510 1-412-029-11 INDUCTOR 10UH
L5000 1-414-394-11 INDUCTOR 2.2UH
L5001 1-414-394-11 INDUCTOR 2.2UH
L5002 1-414-394-11 INDUCTOR 2.2UH
L5003 1-414-394-11 INDUCTOR 2.2UH
L5004 1-400-179-21 INDUCTOR 0UH
L5005 1-400-179-21 INDUCTOR 0UH
L5006 1-216-801-11 METAL CHIP 22 5% 1/10W
L5007 1-216-801-11 METAL CHIP 22 5% 1/10W
L5008 1-456-984-11 INDUCTOR 0UH
L5009 1-456-984-11 INDUCTOR 0UH
L5010 1-400-179-21 INDUCTOR 0UH
L5012 1-456-984-11 INDUCTOR 0UH
L5013 1-456-984-11 INDUCTOR 0UH
L5014 1-456-984-11 INDUCTOR 0UH
L5015 1-400-179-21 INDUCTOR 0UH
L5700 1-409-529-41 INDUCTOR 10UH
L5701 1-456-786-21 INDUCTOR 47UH
L5702 1-456-786-21 INDUCTOR 47UH
L5729 1-400-784-21 INDUCTOR 4.7UH
L6308 1-412-026-11 INDUCTOR 1UH
L6316 1-412-029-11 INDUCTOR 10UH
L6317 1-412-029-11 INDUCTOR 10UH
L7803 1-412-029-11 INDUCTOR 10UH
L7805 1-412-990-41 INDUCTOR 8.2UH
L7806 1-412-029-11 INDUCTOR 10UH
L7807 1-412-029-11 INDUCTOR 10UH
L9500 1-412-029-11 INDUCTOR 10UH
L9502 1-412-030-11 INDUCTOR 22UH
L9510 1-412-030-11 INDUCTOR 22UH
< TRANSISTOR >
Q2501 8-729-010-05 TRANSISTOR MSB709-RT1
Q2502 8-729-010-05 TRANSISTOR MSB709-RT1
Q2503 8-729-010-05 TRANSISTOR MSB709-RT1
Q2504 8-729-010-05 TRANSISTOR MSB709-RT1
Q2505 8-729-010-29 TRANSISTOR MSD601-RST1
Q2506 8-729-029-00 TRANSISTOR DTC115EUA-T106
Q2508 8-729-029-00 TRANSISTOR DTC115EUA-T106
Q2509 8-729-010-29 TRANSISTOR MSD601-RST1
Q2510 8-729-010-29 TRANSISTOR MSD601-RST1
Q2513 8-729-010-29 TRANSISTOR MSD601-RST1
Q2514 8-729-010-29 TRANSISTOR MSD601-RST1
Q2601 8-729-029-00 TRANSISTOR DTC115EUA-T106
Q3878 8-729-010-29 TRANSISTOR MSD601-RST1
Q3880 8-729-010-05 TRANSISTOR MSB709-RT1
Q3881 8-729-010-29 TRANSISTOR MSD601-RST1
Q5700 8-729-046-04 TRANSISTOR FDS6690A
Q7412 8-729-028-28 TRANSISTOR 2SK2036(TE85L)
Q7416 8-729-010-05 TRANSISTOR MSB709-RT1
Q7800 8-729-010-29 TRANSISTOR MSD601-RST1
Q7801 8-729-010-29 TRANSISTOR MSD601-RST1
Q7802 8-729-010-29 TRANSISTOR MSD601-RST1
Q7803 8-729-010-29 TRANSISTOR MSD601-RST1
Q7806 8-729-010-29 TRANSISTOR MSD601-RST1
Q7810 8-729-010-29 TRANSISTOR MSD601-RST1
Q7811 8-729-010-05 TRANSISTOR MSB709-RT1
Q8490 8-729-010-29 TRANSISTOR MSD601-RST1
Q9500 8-729-010-29 TRANSISTOR MSD601-RST1
Q9510 8-729-927-99 TRANSISTOR 2SC4617R
Q9511 8-729-927-99 TRANSISTOR 2SC4617R
Q9512 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9514 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9515 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9516 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9601 8-729-010-29 TRANSISTOR MSD601-RST1
Q9602 6-550-014-01 TRANSISTOR SSM6N15FU(TE85R)
Q9603 8-729-010-05 TRANSISTOR MSB709-RT1
Q9604 8-729-421-19 TRANSISTOR UN2213
Q9605 8-729-010-29 TRANSISTOR MSD601-RST1
Q9606 8-729-028-28 TRANSISTOR 2SK2036(TE85L)
Q9607 8-729-028-28 TRANSISTOR 2SK2036(TE85L)
< RESISTOR >
R1001 1-216-809-11 METAL CHIP 100 5% 1/10W
R1002 1-218-990-81 SHORT CHIP 0
R1003 1-218-990-81 SHORT CHIP 0
R1009 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
