Sony KDL-26S3000 Training Manual

CTV41 58
Chapter 3. Disassembly
FIGURE 3-1
CIRCUIT BOARD ACCESS
WALL MOUNT BRACKETS
FOR ALL MODELS CAN BE
REMOVED FOR ACCESS TO
CIRCUIT BOARDS. BOTTOM
IS SECURED WITH MACHINE
SCREW AND TOP HOOKS
ONTO UPPER MOUNTS.
OBSERVE LEFT AND RIGHT
MARKINGS WHEN RE
-
INSTALLING WALL MOUNT
BRACKETS
.
FIGURE 3-1
CIRCUIT BOARD ACCESS
