30 Additional Information
Additional Information
x Connecting the 3D WOOFER
You can enjoy high quality sound by connecting the 3D WOOFER as follows:
Notes
• Connect only the supplied 3D WOOFER; otherwise your TV may malfunction.
• Unplug your TV from the wall outlet when connecting the 3D WOOFER.
• To prevent a malfunction caused by a short circuit of the terminals, make sure that none of the 3D
WOOFER wire strands stick out, making contact with the neighbouring 3D WOOFER terminal.
Black wire
Red wire
Step 1 Step 2
3D WOOFER
x Connecting optional components
Connecting to the video input terminal ( t )
L(MONO)
R
4
Camcorder
Video game
equipment
TV front panel
S Video cable
(not supplied)
Audio cable
(not supplied)
Audio/Video cable
(not supplied)
CD player
Walkman
To Next Page
