Sony KV-SR29 - Connecting to the Monitor Output Terminal ( T)

31
Additional Information
123
RLY
C
B
C R
123
RLY
C
B
CR
Audio system
VCR
Audio/Video
cable
(not supplied)
Connecting to the monitor output terminal ( T )
TV rear panel
Notes
• If you connect a VCR to 8 (antenna input), preset the signal output from the VCR to the
program number 0 on the TV (see page 27).
• When both (S video) and (video) for t1 or t4 are connected at the same time,
(S video) is automatically selected. To view (video), disconnect the S video cable.
VCR
Audio/Video
cable
(not supplied)
Antenna cable
(not supplied)
TV rear panel
S Video cable
(not supplied)
continue
