Sony lmd-b170 - Page 32

Dimensions
32
LMD-B170
Front
Rear
Side
Unit: mm (inches)
Mass:
Approx. 5.9 kg (13 lb 0.1 oz)
Approx. 4.1 kg (9 lb 0.6 oz) (When the monitor stand
is removed)
Unit: mm (inches)
4-M4 hole
* Length of M4 screws (rear)
Monitor cabinet
Attached object
M4 screw
7 (
9
/
32
) to 10 (
13
/
32
)
Torque: 1.2 ± 0.1 N·m
