MVC-FD80/90/95 DISASSEMBLY 2
3/7/01
5DSC1
AC IN
FU-140 board (MVC-FD90)
FU-146 board (MVC-FD85)
FC-82 board
PK-52 board (MVC-FD85)
PK-50 board (MVC-FD90)
Liquid crystal module
indicator (24p)
Cold cathode
fluroescent tube (20p)
MVC-FD90
FC-72
board
Lens block
assembly (24P)
CD-246
board
Lens block assembly
(MVC-FD90)
Lens block assembly
(MVC-FD85)
CD-248 board
AC POWER
ADAPTOR
