2
CIRCUIT BOARDS LOCATION
3/7/01
1DSC1
PK-50 (MVC-FD90)
PK-52 (MVC-FD85)
CD-236 (MVC-FD90)
FC-72
MAIN BOARD
FU-140 (MVC-FD90)
FU-146 (MVC-FD85)
CD-248 (MVC-FD85)
FLASH UNIT
