RM-95 - Test Switches
Activating the push buttons or switches and you will see the data change
at one of four address locations. This is how you know the switch itself
works.
1. Enter the one of the following address locations with the RM-95 and
press a corresponding button on the Mavica. If the data changes while
the button is pressed, the button is good.
Buttons / Switch Tested Page Address Data
Power, Disc In switch,
Movie, Still, Play.
243
Focus Man/Auto (Manual
focus is not on all models)
254
Control Up, Dwn, Display,
Volume +/-,
255
Control Right, Left, Enter,
Flash, Program, Backlight.
256
Changes when
camera button is
pressed.
Failure Codes
There are error codes held in the self-diagnostics section and appear on
the LCD screen. They are lost when power is removed.
C:32:01 = Defective floppy disc
C:13:01 = Unformated disc, damaged data, or low capacity disc
E:91:01 = Defective flash
E:61:10 = Defective lens. No focus movement
