Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MEX-BT4100E/BT4100P/BT4100U/BT4150U
52
R933 1-216-806-11 METAL CHIP 56 5% 1/10W
R934 1-216-805-11 METAL CHIP 47 5% 1/10W
R935 1-216-804-11 METAL CHIP 39 5% 1/10W
R936 1-216-808-11 METAL CHIP 82 5% 1/10W
R937 1-216-810-11 METAL CHIP 120 5% 1/10W
R938 1-216-809-11 METAL CHIP 100 5% 1/10W
R939 1-216-809-11 METAL CHIP 100 5% 1/10W
R940 1-216-807-11 METAL CHIP 68 5% 1/10W
R941 1-216-807-11 METAL CHIP 68 5% 1/10W
R942 1-216-810-11 METAL CHIP 120 5% 1/10W
R943 1-216-808-11 METAL CHIP 82 5% 1/10W
R944 1-216-808-11 METAL CHIP 82 5% 1/10W
R945 1-216-806-11 METAL CHIP 56 5% 1/10W
R946 1-216-805-11 METAL CHIP 47 5% 1/10W
R947 1-216-804-11 METAL CHIP 39 5% 1/10W
R948 1-216-808-11 METAL CHIP 82 5% 1/10W
R949 1-218-952-11 METAL CHIP 820 5% 1/16W
R950 1-218-953-11 METAL CHIP 1K 5% 1/16W
R951 1-218-953-11 METAL CHIP 1K 5% 1/16W
R952 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R953 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R954 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R955 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R956 1-218-952-11 METAL CHIP 820 5% 1/16W
R957 1-218-953-11 METAL CHIP 1K 5% 1/16W
R958 1-218-953-11 METAL CHIP 1K 5% 1/16W
R959 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R960 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R961 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R962 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R964 1-216-817-11 METAL CHIP 470 5% 1/10W
R965 1-216-817-11 METAL CHIP 470 5% 1/10W
R966 1-216-817-11 METAL CHIP 470 5% 1/10W
R967 1-216-295-91 SHORT CHIP 0
R974 1-216-821-11 METAL CHIP 1K 5% 1/10W
R975 1-216-811-11 METAL CHIP 150 5% 1/10W
R976 1-216-811-11 METAL CHIP 150 5% 1/10W
R980 1-216-809-11 METAL CHIP 100 5% 1/10W
R981 1-216-857-11 METAL CHIP 1M 5% 1/10W
R982 1-216-813-11 METAL CHIP 220 5% 1/10W
R983 1-216-813-11 METAL CHIP 220 5% 1/10W
R984 1-216-809-11 METAL CHIP 100 5% 1/10W
R985 1-216-813-11 METAL CHIP 220 5% 1/10W
R986 1-216-864-11 SHORT CHIP 0
< SWITCH >
S951 1-798-448-11 TACTILE SWITCH (
Z
)
S952 1-798-448-11 TACTILE SWITCH (
OFF, SOURCE)
S953 1-798-448-11 TACTILE SWITCH (SEEK+,
> M
)
S954 1-798-448-11 TACTILE SWITCH ( , MODE)
S955 1-798-448-11 TACTILE SWITCH (
m .
, SEEK–)
S956 1-798-448-11 TACTILE SWITCH (
)
S957 1-798-448-11 TACTILE SWITCH (CALL,
)
S959 1-798-448-11 TACTILE SWITCH ( SCRL, DSPL)
S960 1-798-448-11 TACTILE SWITCH (PAUSE, 6)
S961 1-798-448-11 TACTILE SWITCH (MIC/ZAP, 5)
S962 1-798-448-11 TACTILE SWITCH (SHUF, 4)
S963 1-798-448-11 TACTILE SWITCH ( , 3)
S964 1-798-448-11 TACTILE SWITCH (ALBUM
v
, 2)
S965 1-798-448-11 TACTILE SWITCH (
V
ALBUM, 1)
S966 1-798-448-11 TACTILE SWITCH (
PTY, AF/TA)
(BT4100E/BT4100U)
S966 1-798-448-11 TACTILE SWITCH (CAT, PTY) (BT4100P)
S966 1-798-448-11 TACTILE SWITCH (PTY) (BT4150U)
*************************************************************
A-1890-750-A MAIN BOARD, COMPLETE (BT4100U)
A-1890-751-A MAIN BOARD, COMPLETE (BT4100P)
A-1890-752-A MAIN BOARD, COMPLETE
(BT4100E/BT4150: EA)
A-1890-753-A MAIN BOARD, COMPLETE (BT4150: E, MX)
********************
(Including BT board)
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-794-01 SCREW +PTT 2.6X10 (S)
< CAPACITOR >
C10 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C11 1-137-765-21 ELECT CHIP 47uF 20% 16V
C15 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C100 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C103 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C104 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C105 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C106 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C158 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C201 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C301 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C302 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C303 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C305 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C306 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C307 1-128-394-11 ELECT CHIP 220uF 20% 10V
C308 1-112-863-91 CERAMIC CHIP 0.22uF 10% 10V
C309 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C311 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C313 1-137-765-21 ELECT CHIP 47uF 20% 16V
C314 1-114-983-91 CERAMIC CHIP 2.2uF 10% 16V
C315 1-112-780-11 CERAMIC CHIP 0.47uF 10% 16V
C317 1-112-780-11 CERAMIC CHIP 0.47uF 10% 16V
C319 1-112-780-11 CERAMIC CHIP 0.47uF 10% 16V
C320 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C321 1-112-780-11 CERAMIC CHIP 0.47uF 10% 16V
C323 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C324 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C326 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C327 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C329 1-128-996-11 ELECT CHIP 4.7uF 20% 50V
C330 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C331 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C334 1-112-839-11 ELECT 4700uF 20% 16V
C335 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C351 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C352 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C353 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C354 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C355 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C356 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C357 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
Note 1: When the complete MAIN board is replaced, the destination
setting is necessary. Refer to “NOTE THE MAIN BOARD OR
SYSTEM CONTROLLER (IC501) REPLACING” on page 4.
Note 2: When the complete MAIN board (including BT board)
is replaced, it is necessary to confi rm operation. Refer to
“BLUETOOTH FUNCTION CHECKING METHOD
USING A CELLULAR PHONE” on page 7.
