MEX-BT4100E/BT4100P/BT4100U/BT4150U
SECTION 7
ELECTRICAL PARTS LIST
A-1888-219-A BT BOARD, COMPLETE (Included in MAIN board)
******************
When the BT board is defective, exchange the complete mounted board.
*************************************************************
KEY BOARD
**********
< CAPACITOR >
C900 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C901 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C905 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C906 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C907 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C908 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C909 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C910 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C911 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C912 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C913 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C914 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
< CONNECTOR >
CN901 1-842-265-22 PLUG, CONNECTOR 20P
< DIODE >
D900 6-503-213-01 DIODE RKZ18B2KGP1
D903 6-503-205-01 DIODE RKZ6.8B2KGP1
D904 6-503-205-01 DIODE RKZ6.8B2KGP1
D905 6-503-205-01 DIODE RKZ6.8B2KGP1
D981 6-503-202-01 DIODE RKZ5.1B2KGP1
D982 6-502-961-01 DIODE DA2J10100L
< FERRITE BEAD >
FB901 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB902 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB903 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
< IC >
IC901 6-718-828-02 IC PT16512-LQ
< COIL >
L901 1-457-223-11 COMMON MODE CHOKE COIL
< LED >
LED900
6-503-871-01 LED SMLVN6RGB1U1 (LCD BACK LIGHT)
LED902 6-503-871-01 LED SMLVN6RGB1U1 (RING ILLUMINATION)
LED903 6-503-871-01 LED SMLVN6RGB1U1 (KEY ILLUMINATION)
< TRANSISTOR >
Q900 6-551-272-01 TRANSISTOR RT3CLLM
Q901 6-551-272-01 TRANSISTOR RT3CLLM
Q902 6-551-272-01 TRANSISTOR RT3CLLM
Q903 6-551-272-01 TRANSISTOR RT3CLLM
Q904 6-551-272-01 TRANSISTOR RT3CLLM
Q905 6-551-272-01 TRANSISTOR RT3CLLM
Q906 6-551-272-01 TRANSISTOR RT3CLLM
Q907 6-551-272-01 TRANSISTOR RT3CLLM
Q908 6-551-272-01 TRANSISTOR RT3CLLM
< RESISTOR >
R900 1-216-810-11 METAL CHIP 120 5% 1/10W
R901 1-216-809-11 METAL CHIP 100 5% 1/10W
R903 1-216-810-11 METAL CHIP 120 5% 1/10W
R904 1-216-807-11 METAL CHIP 68 5% 1/10W
R905 1-216-810-11 METAL CHIP 120 5% 1/10W
R906 1-216-808-11 METAL CHIP 82 5% 1/10W
R907 1-216-812-11 METAL CHIP 180 5% 1/10W
R908 1-216-813-11 METAL CHIP 220 5% 1/10W
R909 1-216-810-11 METAL CHIP 120 5% 1/10W
R910 1-216-811-11 METAL CHIP 150 5% 1/10W
R911 1-216-810-11 METAL CHIP 120 5% 1/10W
R912 1-216-811-11 METAL CHIP 150 5% 1/10W
R913 1-216-811-11 METAL CHIP 150 5% 1/10W
R914 1-216-810-11 METAL CHIP 120 5% 1/10W
R915 1-216-807-11 METAL CHIP 68 5% 1/10W
R916 1-216-810-11 METAL CHIP 120 5% 1/10W
R917 1-216-808-11 METAL CHIP 82 5% 1/10W
R922 1-216-833-11 METAL CHIP 10K 5% 1/10W
R923 1-216-833-11 METAL CHIP 10K 5% 1/10W
R924 1-216-833-11 METAL CHIP 10K 5% 1/10W
R925 1-216-833-11 METAL CHIP 10K 5% 1/10W
R926 1-216-833-11 METAL CHIP 10K 5% 1/10W
R927 1-216-833-11 METAL CHIP 10K 5% 1/10W
R928 1-216-833-11 METAL CHIP 10K 5% 1/10W
R929 1-216-833-11 METAL CHIP 10K 5% 1/10W
R930 1-216-833-11 METAL CHIP 10K 5% 1/10W
R931 1-216-807-11 METAL CHIP 68 5% 1/10W
R932 1-216-807-11 METAL CHIP 68 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CND : Canadian model
EA : Saudi Arabia model
MX : Mexican model
RU : Russian model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
Note: When the complete BT board is replaced, it is necessary to con-
fi rm operation. Refer to “BLUETOOTH FUNCTION CHECK-
ING METHOD USING A CELLULAR PHONE” on page 7.
BT KEY
Ver. 1.1
To Next Page
