Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MEX-BT4100E/BT4100P/BT4100U/BT4150U
5555
FB722 1-218-990-81 SHORT CHIP 0
FB724 1-469-084-21 INDUCTOR, FERRITE BEAD (1005)
FB782 1-469-084-21 INDUCTOR, FERRITE BEAD (1005)
FB801 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB802 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB803 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB890 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB891 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB1301 1-216-864-11 SHORT CHIP 0
< IC >
IC301 6-715-848-21 IC TDF8556AJ/N5
IC401 6-714-623-01
IC BD3467FV-E2
IC402 6-716-993-01 IC MM1836A33NRE
IC501 6-719-019-02 IC R5F3650ECDZ98FB (for SERVICE)
(BT4100E/BT4100U/BT4150U)
IC501 6-719-022-02 IC R5F3650KCDZ95FB (for SERVICE) (BT4100P)
IC601 6-715-714-01 IC TMPM320C1DFG-9999
IC602 6-719-044-02 IC W25Q16CVSSIG-A02 (for SERVICE)
IC603 6-717-694-01 IC BU33TD3WG-TR
IC681 6-716-355-01 IC BU15TD3WG-TR
IC682 6-716-355-01 IC BU15TD3WG-TR
IC701 6-715-712-11 IC TC94A99FG-003 (SY, H
IC703 6-715-716-01 IC S-1206B12-U3T1G
IC704 6-718-324-01 IC MFI337S3959
IC830 6-710-376-01 IC 74LVC1G17GW-125 (BT4100P)
IC831 6-709-182-01 IC TC7WH126FK (BT4100P)
IC1300 6-718-913-01 IC OZ539IGN-A1-0-TR
< JACK >
J1 1-843-172-1
1 JACK (ANT) (ANTENNA IN)
J403 1-822-714-21 JACK, PIN 6P
(FRONT/REAR AUDIO OUT, SUB OUT (MONO))
J801 1-566-822-81 JACK (REMOTE IN)
< COIL >
L1 1-400-073-21 INDUCTOR 4.7uH
L301 1-460-443-11 CHOKE COIL 140uH
L395 1-469-844-11 INDUCTOR 2.2uH
L431 1-469-844-11 INDUCTOR 2.2uH
L1301 1-457-630-11 COIL, CHOKE 47uH
< TRANSISTOR >
Q301 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
Q302 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
Q401 6-552-937-01 TRANSISTOR LTC014TUBFS8TL
Q402 6-552-937-01 TRANSISTOR LTC014TUBFS8TL
Q403 6-552-937-01 TRANSISTOR LTC014TUBFS8TL
Q404 6-552-937-01 TRANSISTOR LTC014TUBFS8TL
Q405 6-552-937-01 TRANSISTOR LTC014TUBFS8TL
Q407 6-552-922-01 TRANSISTOR LTA014EUBFS8TL
Q409 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
Q710 6-551-120-01 TRANSISTOR 2SA2119K
Q801 6-552-949-01 TRANSISTOR LTC044EUBFS8TL
Q802 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
Q803 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
< RESISTOR/CAPACITOR >
R10 1-218-990-81 SHORT CHIP 0
R13 1-216-821-11 METAL CHIP 1K 5% 1/10W
R19 1-216-864-11 SHORT CHIP 0 (BT4100E/BT4100U/BT4150U)
R100 1-216-864-11 SHORT CHIP 0
R101 1-216-296-11 SHORT CHIP 0
R102 1-216-864-11 SHORT CHIP 0
R107 1-216-296-11 SHORT CHIP 0
R116 1-216-864-11 SHORT CHIP 0
R200 1-216-864-11 SHORT CHIP 0
R201 1-216-295-91 SHORT CHIP 0
R203 1-216-864-11 SHORT CHIP 0
R300 1-216-296-11 SHORT CHIP 0
R301 1-218-941-81 METAL CHIP 100 5% 1/16W
R302 1-218-941-81 METAL CHIP 100 5% 1/16W
R303 1-216-182-00 METAL CHIP 220 5% 1/8W
R304 1-216-182-00 METAL CHIP 220 5% 1/8W
R305 1-216-182-00 METAL CHIP 220 5% 1/8W
R306 1-216-182-00 METAL CHIP 220 5% 1/8W
R307 1-218-943-11 METAL CHIP 150 5% 1/16W
R308 1-216-864-11 SHORT CHIP 0
R309 1-218-973-11 METAL CHIP 47K 5% 1/16W
R310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R311 1-216-073-91 METAL CHIP 10K 5% 1/10W
R312 1-218-973-11 METAL CHIP 47K 5% 1/16W
R313 1-218-973-11 METAL CHIP 47K 5% 1/16W
R314 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R315 1-218-969-11 METAL CHIP 22K 5% 1/16W
R316 1-218-977-11 METAL CHIP 100K 5% 1/16W
R317 1-216-214-00 METAL CHIP 4.7K 5% 1/8W
R322 1-216-296-11 SHORT CHIP 0
R323 1-216-821-11 METAL CHIP 1K 5% 1/10W
R324 1-216-821-11 METAL CHIP 1K 5% 1/10W
R325 1-216-821-11 METAL CHIP 1K 5% 1/10W
R326 1-216-821-11 METAL CHIP 1K 5% 1/10W
R340 1-216-864-11 SHORT CHIP 0
R378 1-216-073-91 METAL CHIP 10K 5% 1/10W
R387 1-216-864-11 SHORT CHIP 0
R396 1-216-296-11 SHORT CHIP 0
R400 1-216-864-11 SHORT CHIP 0
R404 1-218-945-11 METAL CHIP 220 5% 1/16W
R405 1-216-841-11 METAL CHIP 47K 5% 1/10W
R407 1-218-945-11 METAL CHIP 220 5% 1/16W
R409 1-216-833-11 METAL CHIP 10K 5% 1/10W
R410 1-218-945-11 METAL CHIP 220 5% 1/16W
R411 1-216-833-11 METAL CHIP 10K 5% 1/10W
R412 1-218-990-81 SHORT CHIP 0
R415 1-216-821-11 METAL CHIP 1K 5% 1/10W
R416 1-216-821-11 METAL CHIP 1K 5% 1/10W
R417 1-218-966-11 METAL CHIP 12K 5% 1/16W
R418 1-218-966-11 METAL CHIP 12K 5% 1/16W
R419 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R421 1-218-945-11 METAL CHIP 220 5% 1/16W
R422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R423 1-218-945-11 METAL CHIP 220 5% 1/16W
R424 1-216-833-11 METAL CHIP 10K 5% 1/10W
R425 1-216-864-11 SHORT CHIP 0
R426 1-216-296-11 SHORT CHIP 0
R427 1-218-990-81 SHORT CHIP 0
R429 1-218-933-11 METAL CHIP 22 5% 1/16W
R432 1-218-965-11 METAL CHIP 10K 5% 1/16W
R433 1-216-296-11 SHORT CHIP 0
R434 1-216-295-91 SHORT CHIP 0
Note: When IC501 is replaced, the destination setting is necessary. Refer to “NOTE THE
MAIN BOARD OR SYSTEM CONTROLLER (IC501) REPLACING” on page 4.
MAIN
Ver. 1.1
To Next Page
