Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MEX-BT4100E/BT4100P/BT4100U/BT4150U
5757
R711 1-218-929-11 METAL CHIP 10 5% 1/16W
R712 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R714 1-218-990-81 SHORT CHIP 0
R715 1-216-864-11 SHORT CHIP 0
R716 1-218-990-81 SHORT CHIP 0
R717 1-218-947-11 METAL CHIP 330 5% 1/16W
R718 1-218-947-11 METAL CHIP 330 5% 1/16W
R719 1-218-947-11 METAL CHIP 330 5% 1/16W
R720 1-218-947-11 METAL CHIP 330 5% 1/16W
R721 1-218-947-11 METAL CHIP 330 5% 1/16W
R722 1-218-989-11 METAL CHIP 1M 5% 1/16W
R723 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R724 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R725 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R726 1-218-965-11 METAL CHIP 10K 5% 1/16W
R727 1-218-965-11 METAL CHIP 10K 5% 1/16W
R732 1-218-941-81 METAL CHIP 100 5% 1/16W
R733 1-218-941-81 METAL CHIP 100 5% 1/16W
R736 1-218-977-11 METAL CHIP 100K 5% 1/16W
R740 1-218-953-11 METAL CHIP 1K 5% 1/16W
R741 1-218-941-81 METAL CHIP 100 5% 1/16W
R742 1-216-841-11 METAL CHIP 47K 5% 1/10W
R743 1-218-967-11 METAL CHIP 15K 5% 1/16W
R744 1-218-983-11 METAL CHIP 330K 5% 1/16W
R745 1-218-941-81 METAL CHIP 100 5% 1/16W
R746 1-218-990-81 SHORT CHIP 0
R747 1-218-990-81 SHORT CHIP 0
R748 1-218-990-81 SHORT CHIP 0
R749 1-218-990-81 SHORT CHIP 0
R750 1-218-969-11 METAL CHIP 22K 5% 1/16W
R751 1-218-969-11 METAL CHIP 22K 5% 1/16W
R763 1-216-864-11 SHORT CHIP 0
R765 1-216-864-11 SHORT CHIP 0
R766 1-216-864-11 SHORT CHIP 0
R767 1-218-977-11 METAL CHIP 100K 5% 1/16W
R768 1-250-337-21 METAL CHIP 44.2 1% 1/10W
R770 1-218-941-81 METAL CHIP 100 5% 1/16W
R790 1-216-864-11 SHORT CHIP 0
R818 1-218-981-91 METAL CHIP 220K 5% 1/16W
R819 1-218-953-11 METAL CHIP 1K 5% 1/16W
R820 1-218-953-11 METAL CHIP 1K 5% 1/16W
R830 1-218-972-11 METAL CHIP 39K 5% 1/16W
(BT4100P)
R831 1-218-977-11 METAL CHIP 100K 5% 1/16W
(BT4100P)
R833 1-218-975-11 METAL CHIP 68K 5% 1/16W
(BT4100P)
R833 1-218-977-11 METAL CHIP 100K 5% 1/16W
(BT4100E/BT4100U/BT4150U)
R834 1-218-977-11 METAL CHIP 100K 5% 1/16W
(BT4100P)
R836 1-216-801-11 METAL CHIP 22 5% 1/10W
(BT4100P)
R837 1-216-864-11 SHORT CHIP 0 (BT4100P)
R855 1-216-809-11 METAL CHIP 100 5% 1/10W
(BT4100P)
R856 1-216-809-11 METAL CHIP 100 5% 1/10W
(BT4100P)
R857 1-216-809-11 METAL CHIP 100 5% 1/10W
(BT4100P)
R864 1-216-864-11 SHORT CHIP 0
R870 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
(BT4100P)
R871 1-218-966-11 METAL CHIP 12K 5% 1/16W
(BT4100P)
R872 1-218-966-11 METAL CHIP 12K 5% 1/16W
(BT4100P)
R873 1-216-864-11 SHORT CHIP 0 (BT4100P)
R874 1-216-821-11 METAL CHIP 1K 5% 1/10W
(BT4100P)
R875 1-216-821-11 METAL CHIP 1K 5% 1/10W
(BT4100P)
R899 1-216-295-91 SHORT CHIP 0
R1300 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1301 1-216-809-11 METAL CHIP 100 5% 1/10W
R1302 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1305 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1307 1-208-933-11 METAL CHIP 82K 0.5% 1/16W
R1308 1-208-933-11 METAL CHIP 82K 0.5% 1/16W
R1311 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R1312 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1313 1-218-979-11 METAL CHIP 150K 5% 1/16W
R1314 1-216-296-11 SHORT CHIP 0
R1315 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1316 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1320 1-218-953-11 METAL CHIP 1K 5% 1/16W
< VIBRATOR >
X501 1-814-626-11 VIBRATOR, CRYSTAL (7.92 MHz)
X502 1-814-629-11 VIBRATOR, CRYSTAL (32.768 kHz)
X601 1-814-304-11 VIBRATOR, CRYSTAL (12 MHz)
X701 1-795-561-21 VIBRATOR, CERAMIC (16.934 MHz)
*************************************************************
SENSOR BOARD
*************
When the SENSOR board is defective, exchange the MECHANICAL BLOCK ASSY.
*************************************************************
A-1866-089-A SERVO BOARD, COMPLETE
**********************
When the SERVO board is defective, exchange the complete mounted board.
*************************************************************
MISCELLANEOUS
**************
CCB1 1-780-968-11 CONDUCTIVE BOARD, CONNECTION
CDM1 A-1866-801-A MECHANICAL BLOCK (11CA) ASSY
(US, CND, AEP, RU, UK, E, MX)
CDM1 A-1922-404-A MECHANICAL BLOCK (11CA2) ASSY (EA)
CN971 1-822-798-11 USB CONNECTOR (
)
0 DAX1 A-1284-705-A DAXEV08
FP1 A-1890-760-A PANEL OVERALL ASSY, FRONT (BT4100U)
FP1 A-1890-761-A PANEL OVERALL ASSY, FRONT (BT4100P)
FP1 A-1890-762-A PANEL OVERALL ASSY, FRONT (BT4100E)
FP1 A-1890-763-A PANEL OVERALL ASSY, FRONT (BT4150U)
FU1 1-523-227-11 MINI FUSE (BLADE TYPE) (10 A/32 V)
IC902 6-600-806-01 IC PNJ4813M01S0 (
)
J901 1-842-936-12 JACK (SMALL TYPE) (DIA. 3.5) (AUX)
LCD901 1-811-485-11 DISPLAY P
ANEL, LIQUID CRYSTAL
MJ1 1-846-310-11 CABLE, CONNECTION (MIC) (MIC IN)
0 OP1 X-2149-672-1 OPTICAL PICK-UP (DAX-25A) (for SERVICE)
MAIN SENSOR SERVO
Note: Refer to the servicing notes “NOTE FOR REPLACEMENT
OF THE USB CONNECTOR (CN971) AND THE AUX
JACK (J901)” on page 6, if replacing CN971 and J901.
Ver. 1.1
