11
MEX-BT4100E/BT4100P/BT4100U/BT4150U
3. ELECTRICAL PARTS LIST
A-1890-750-A MAIN BOARD, COMPLETE (BT4100U)
A-1890-751-A MAIN BOARD, COMPLETE (BT4100P)
A-1890-752-A MAIN BOARD, COMPLETE
(BT4100E/BT4150: EA)
A-1890-753-A MAIN BOARD, COMPLETE (BT4150: E, MX)
********************
(Including BT board)
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-794-01 SCREW +PTT 2.6X10 (S)
< CAPACITOR >
C10 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C11 1-137-765-21 ELECT CHIP 47uF 20% 16V
C15 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C100 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C103 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C104 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C105 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C106 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C158 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C201 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C301 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C302 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C303 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C305 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C306 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C307 1-128-394-11 ELECT CHIP 220uF 20% 10V
C308 1-112-863-91 CERAMIC CHIP 0.22uF 10% 10V
C309 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C311 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C313 1-137-765-21 ELECT CHIP 47uF 20% 16V
C314 1-114-983-91 CERAMIC CHIP 2.2uF 10% 16V
C315 1-112-780-11 CERAMIC CHIP 0.47uF 10% 16V
C317 1-112-780-11 CERAMIC CHIP 0.47uF 10% 16V
C319 1-112-780-11 CERAMIC CHIP 0.47uF 10% 16V
C320 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C321 1-112-780-11 CERAMIC CHIP 0.47uF 10% 16V
C323 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C324 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C326 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C327 1-116-733-11 CERAMIC CHIP 1uF 10% 25V
C329 1-128-996-11 ELECT CHIP 4.7uF 20% 50V
C330 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C331 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C334 1-112-839-11 ELECT 4700uF 20% 16V
C335 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C351 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C352 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C353 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C354 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C355 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C356 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C357 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C358 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C359 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C364 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C365 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C366 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C367 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C387 1-128-398-11 ELECT CHIP 220uF 20% 16V
C398 1-100-905-11 CERAMIC CHIP 0.001uF 10% 50V
C399 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C401 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C402 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C403 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C407 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C411 1-127-931-21 ELECT CHIP 470uF 20% 16V
C412 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C413 1-124-779-00 ELECT CHIP 10uF 20% 16V
C414 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C416 1-128-992-21 ELECT CHIP 47uF 20% 25V
C419 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C420 1-124-779-00 ELECT CHIP 10uF 20% 16V
C421 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C422 1-116-728-11 CERAMIC CHIP 2.2uF 10% 10V
C423 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C424 1-124-779-00 ELECT CHIP 10uF 20% 16V
C425 1-124-779-00 ELECT CHIP 10uF 20% 16V
C426 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C431 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C432 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C434 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C435 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C436 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C437 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C438 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C439 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C440 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
EA : Saudi Arabia model
MX : Mexican model
Note 1: When the complete MAIN board is replaced, the destination
setting is necessary. Refer to “NOTE THE MAIN BOARD
OR SYSTEM CONTROLLER (IC501) REPLACING” on
page 4 on original service manual.
Note 2: When the complete MAIN board (including BT board) is re-
placed, it is necessary to confi rm operation. Refer to “BLUE-
TOOTH FUNCTION CHECKING METHOD USING A CEL-
LULAR PHONE” on page 7 on original service manual.
MAIN
To Next Page
