8
Location and function of controls
Main unit
Front panel removed
Refer to the pages listed for details.
Instructions in this manual generally describe the
controls on the card remote commander. You can
also use the controls on the main unit if they have
the same or similar names to those on the card
remote commander.
A OFF button 12, 14, 16, 21
To power off/stop the source (press); shut off
completely (press and hold).
B m (Microphone) button 30
To activate the karaoke mode.
C Volume control dial/SOUND/ENTER
button 12, 24, 31, 32, 34, 37, 38, 43,
47, 48
To adjust the volume/adjust a setting (rotate);
open the sound menu/apply a setting (press).
D SOURCE button 12, 13, 18, 34, 48
To power on; change the source (Radio/Disc/
AUX/SAT*
1
).
E Display window
OFF
OPEN
DSPL
SCRL
SEEK SEEK
ALBUM
REP SHUF
AUX
PUSH SOUND/
ENTER
123456
MODELIST
SOURCE
SYSTEM
SETUP
1
q;
9 qa qdqs
2 4 5
8
67
3
MEX-DV2000
qgqf
RESET
j
k
h
