94
GB
Amplifier section
The following measured at AC 127, 220, 240 V,
50/60 Hz (Saudi Arabian model only)
The following measured at AC 120, 220, 240 V,
50/60 Hz (except for Saudi Arabian model)
DIN power output at stereo mode (rated)
100 + 100 watts (6 ohms at
1 kHz, DIN)
Continuous RMS power output (reference)
Front speaker: 140 + 140 watts (6 ohms at
1 kHz, 10% THD)
Center speaker: 40 watts (6 ohms at 1 kHz,
10% THD)
Surround speaker: 40 + 40 watts (6 ohms at
1 kHz, 10% THD)
Inputs
VIDEO/SAT IN L/R (phono jacks):
Voltage 250 mV/450 mV,
impedance 47 kilohms
MIC 1/2 (phone jack): sensitivity 1 mV,
impedance 10 kilohms
Outputs
VIDEO/SAT OUT L/R (phono jacks):
Voltage 250 mV,
impedance 1 kilohms
SUB WOOFER OUT: Voltage 1 V,
impedance 1 kilohms
VIDEO OUT (phono jacks):
max. output level
1 Vp-p, unbalanced, Sync
negative, load impedance
75 ohms
S VIDEO OUT (4-pin/mini-DIN jack):
Y: 1 Vp-p, unbalanced,
Sync negative,
C: 0.286 Vp-p,
load impedance 75 ohms
COMPONENT VIDEO OUT:
Y: 1 Vp-p, 75 ohms
PB/CB: 0.7 Vp-p, 75 ohms
PR/CR: 0.7 Vp-p, 75 ohms
PHONES (stereo mini jack):
accepts headphones of
8 ohms or more
FRONT L/R: Use only the supplied
speaker SS-WZ88D
SURROUND L/R: Use only the supplied
speaker SS-RSZ88D
CENTER: Use only the supplied
speaker SS-CTZ88D
Disc player section
System Compact disc and digital
audio and video system
Laser Semiconductor laser
(DVD: λ = 650 nm,
CD: λ = 790 nm)
Emission duration:
continuous
Frequency response DVD (PCM 48 kHz):
2 Hz – 22 kHz (±1dB)
CD: 2 Hz – 20 kHz
(±0.5 dB)
Video color system format
Latin American models NTSC
Russian models PAL
Other models NTSC, PAL
Tape deck section
Recording system 4-track 2-channel stereo
Frequency response 50 – 13,000 Hz (±3 dB),
using Sony TYPE I tape
Wow and flutter ±0.15% W.Peak (IEC)
0.1% W.RMS (NAB)
±0.2% W.Peak (DIN)
Specifications
