MP-CL1 3-MP0-107-02
Jog lever (−/ENTER/+)
Press the jog lever while at the ENTER position to display the menu. Slide it to + or
− to move to next or previous menu item, then press while at the ENTER position to
select the highlighted item.
Speaker
Built-in Wi-Fi antenna
HDMI/MHL IN jack
AUDIO OUT jack
Connect headphones or speakers to this jack.
USB OUT jack (for power supply)
Connect another device to this jack to charge it. The
lamp lights up in green
while charging the device.
Ventilation holes
(charge) lamp
(power) lamp
Lens
Laser radiates from this aperture.
