Chapter 2 Location and Function of Parts
Chapter 2 Location and Function of Parts 2-1
2-1 Control Panels
There are three control panels, as follows:
•Upper control panel
• Lower control panel
•Switch panel
Chapter 2 Location and Function of Parts
VID. IN PB/EE CONFI CTL/TC
Y-R,B
PB
OFF TC
MENU
TCGSET
ON
OFF
KEY INHI
FRONTREAR
PANEL SEL
CONTROL PANEL
Z
REMOTE
NETWORK 1 (9P) 2 (50P) RS-232C
Lower control panel unlock buttons
Pushing in these buttons allows you to open the lower control panel.
Upper control panel
(see page 2-2)
Lower control panel
(see page 2-4)
Switch panel (access by opening the lower control panel)
(see page 2-16)
MSW-M2000E/M2000EP
MSW-A2000/A2000P/M2000/M2000P/2000
