Chapter 3 Preparations
3-8 Chapter 3 Preparations
•Connections for playback
• SDI OUTPUT
• COMPOSITE
• COMPONENT
REF. VIDEO
INPUT
Reference signal
Video monitor
MSW-A2000/A2000P/M2000/M2000P/2000/
M2000E/M2000EP
a)
75 Ω termination switch: ON
3-2 Reference Signals for Video Output and Servo System
a) The figure shows the MSW-M2000/ M2000P.
